XPressArray
0.18碌 Hybrid Gate Array
1.0 Key Features
鈥?Next-generation 0.18碌 hybrid gate array
鈥?Platform for high-performance 1.8V ASICs and FPGA-to-
ASIC conversions
鈥?NRE and production cost savings
鈥?Significant time-to-market advantages
鈥?Drop-in replacement for cost-reducing Xilinx Virtex-E and
Altera APEX-E designs
鈥?47K to 2.6M ASIC gates, 240K to 11M FPGA system gates
鈥?250MHz system, 350MHz local clock speeds
鈥?Low power consumption (0.020碌W/MHz/gate)
鈥?23Kbits to 1.4Mbits of embedded configurable memory
鈥?Single-port/dual-port, RAM/CAM, initializable
鈥?Flexible I/O technology
鈥?Configurable signal, core and I/O power supply pad
locations
鈥?Supports LVTTL, LVCMOS, PCI, PCI-X, AGP-2X, HSTL,
SSTL, GTL/+, LVPECL, LVDS, BLVDS
鈥?1.8V, 2.5V and 3.3V capable I/O
鈥?True 3.3V and 5V tolerance with no external resistor
necessary
鈥?Up to 832 user I/Os
鈥?Comprehensive clock management circuitry
鈥?Up to 12 digital DLLs and 4 PLLs
鈥?Variety of package options
鈥?Integrated scan-test and JTAG support for high-fault
coverage
2.0 Product Description
Targeted at medium-density, high-speed, 1.8V ASIC applications
and high-density FPGA-to-ASIC conversions, the XPressArray
0.18碌 hybrid gate array is an innovative next-generation
technology platform that reduces time-to-market for system-on-
chip (SoC) applications while delivering significant NRE and unit
cost savings.
XPressArray offers a true drop-in replacement for Xilinx Virtex-E
and Altera APEX-E FPGAs, making it the industry鈥檚 lowest cost
ASIC conversion solution. The result is a simplified route to cost
reductions for OEMs looking to combine the flexibility of FPGA
prototyping with a path to ASICs for final production.
Operating with system clock speeds up to 250MHz and local
clocks up to 350MHz and available in a variety of package
options, XPressArray 0.18碌 devices deliver high-performance,
low power ASIC solutions with densities to 2.6M ASIC gates.
Embedded configurable memory ranges from 23Kbits to
1.4Mbits, while flexible I/O technology includes support for a
comprehensive array of common standards and compatibility
with 1.8V, 2.5V, 3.3V and 5.0V I/O schemes. High fault coverage
is provided through integrated scan-test and JTAG support.
For FPGA conversions rapid access to XPressArray technology
can be achieved via AMI Semiconductor鈥檚 NETRANS
廬
FPGA-to-
ASIC design flow. Alternatively, the availability of XPressArray
synthesis libraries for leading commercial synthesizers allows
conversion of FPGA designs to ASICs by simply re-targeting
from an FPGA library to an XPressArray library.
