ST92F124/ST92F150/ST92F250
8/16-BIT SINGLE VOLTAGE FLASH MCU FAMILY WITH RAM,
E
3 TM
(EMULATED EEPROM), CAN 2.0B AND J1850 BLPD
PRELIMINARY DATA
s
Memories
鈥?Internal Memory: Single Voltage FLASH up to 256
Kbytes, RAM up to 8Kbytes, 1K byte E
3 TM
(Emulat-
ed EEPROM)
鈥?In-Application Programming (IAP)
鈥?224 general purpose registers (register file) availa-
ble as RAM, accumulators or index pointers
TQFP64
14x14
PQFP100
14x20
s
Clock, Reset and Supply Management
鈥?Register-oriented 8/16 bit CORE with RUN, WFI,
SLOW, HALT and STOP modes
鈥?0-24 MHz Operation (Int. Clock), 4.5-5.5 V range
鈥?PLL Clock Generator (3-5 MHz crystal)
鈥?Minimum instruction time: 83 ns (24 MHz int. clock)
80, 77 or 48 I/O pins (depending on device)
TQFP100
14x14
鈥?One Multiprotocol Serial Communications Interface
with asynchronous and synchronous capabilities
鈥?One asynchronous Serial Communications Interface
(on 100-pin versions only) with 13-bit LIN Synch
Break generation capability
鈥?J1850 Byte Level Protocol Decoder (JBLPD)
(on F150J versions only)
鈥?One or two full I虜C multiple Master/Slave Interfaces
supporting Access Bus
鈥?One or two CAN 2.0B (150 version only) Active inter-
faces
10-bit Analog to Digital Converter allowing up to 16
input channels on 100-pin devices or 8 input channels
on 64-pin devices
s
s
Interrupt Management
鈥?80, 77 or 48 I/O pins (depending on device)
鈥?4 external fast interrupts + 1 NMI
鈥?Up to 16 pins programmable as wake-up or addition-
al external interrupt with multi-level interrupt handler
鈥?DMA controller for reduced processor overhead
s
Timers
鈥?16-bit Timer with 8-bit Prescaler, and Watchdog Tim-
er (activated by software or by hardware)
鈥?16-bit Standard Timer that can be used to generate
a time base independent of PLL Clock Generator
鈥?Two 16-bit independent Extended Function Timers
(EFTs) with Prescaler, 2 Input Captures and two
Output Compares (100-pin devices only)
鈥?Two 16-bit Multifunction Timers, with Prescaler, 2 In-
put Captures and two Output Compares
s
s
Development Tools
鈥?Free High performance Development environment
(IDE) based on Visual Debugger, Assembler, Linker,
and C-Compiler; Real Time Operating System (OS-
EK OS, CMX) and CAN drivers
鈥?Hardware Emulator and Flash Programming Board
for development and ISP Flasher for production
s
Communication Interfaces
鈥?Serial Peripheral Interface (SPI) with Selectable
Master/Slave mode
DEVICE SUMMARY
Features
FLASH - bytes
RAM - bytes
E
3 TM
- bytes
Timers and Serial
Interface
ADC
Network Interface
Temp. Range
Packages
ST92F124R9
64K
2K
1K
2 MFT, STIM,
WD, SCI, SPI,
I虜C
8 x 10 bits
ST92F124V1 ST92F150C(R/V)1 ST92F150JDV1
ST92F250CV2
128K
128K
128K
256K
4K
4K
6K
8K
1K
1K
1K
1K
2 MFT, 2 EFT, STIM,
2 MFT, 2 EFT,
2 MFT, 2 EFT, 2 MFT, 0/2 EFT,
WD, 2 SCI,
STIM, WD,
STIM, WD,
STIM, WD,
SPI, 2 I虜C
1)
2 SCI, SPI, I虜C
2 SCI, SPI, I虜C 1/2 SCI, SPI, I虜C
16 x 10 bits
8/16 x 10 bits
16 x 10 bits
-
CAN
2 CAN, J1850
CAN, LIN Master
-40擄C to 105擄C ,
-40擄C to 105擄C ,
o
o
-40擄C to 85擄C -40擄C to 105擄C
2)
-40 C to 125 C
-40擄C to 125擄C
-40擄C to 125擄C
2)
P/TQFP100 and
TQFP64
PQFP100
P/TQFP100
TQFP64
1) see
Section 12.3 on page 396
for important information
2) see
Table 70 on page 393
Rev. 1.3
December 2002
1/398
This is preliminary information on a new product now in development or undergoing evaluation. Details are subject to change without notice.
