NTE92 (NPN) & NTE93 (PNP)
Silicon Complementary Transistors
Hi鈥揊i Power Amp, Audio Ourtput
Absolute Maximum Ratings:
(T
A
= +25擄C unless otherwise specified)
Collector鈥揃ase Voltage, V
CBO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200V
Collector鈥揈mitter Voltage, V
CEO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200V
Emitter鈥揃ase Voltage, V
EBO
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6V
Collector Current, I
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15A
Base Current, I
B
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5A
Collector Power Dissipation (T
C
= +25擄C), P
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150W
Junction Temperature, T
J
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +150擄C
Storage Temperature Range, T
stg
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 鈥?5擄 to +150擄C
Note 1. Matched complementary pairs are available upon request (NTE93MCP). Matched comple-
mentary pairs have their gain specification (h
FE
) matched to within 10% of each other.
Electrical Characteristics:
(T
A
= +25擄C unless otherwise specified)
Parameter
Collector Cutoff Current
Emitter Cutoff Current
Collector鈥揈mitter Breakdown Voltage
DC Current Gain
Collector鈥揈mitter Saturation Voltage
Transistion Frequency
Symbol
I
CBO
I
EBO
h
FE
V
CE(sat)
f
T
Test Conditions
V
CB
= 200V
V
BE
= 6V
V
CE
= 4V, I
C
= 5A
I
C
= 10A, I
B
= 1A
V
CE
= 12V, I
E
= 0.5A
Min
鈥?/div>
鈥?/div>
200
30
鈥?/div>
鈥?/div>
Typ
鈥?/div>
鈥?/div>
鈥?/div>
120
3
20
Max
0.1
0.1
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
V
MHz
Unit
mA
mA
V
V
(BR)CEO
I
C
= 50mA
