NCP565/D Datasheet

  • NCP565/D

  • 1.5A Adjustable Low Dropout Linear Regulator with Fast Trans...

  • 12頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

NCP565
1.5 A Low Dropout
Linear Regulator
The NCP565 low dropout linear regulator will provide 1.5 A at a
fixed output voltage and an adjustable voltage down to 0.9 V. The fast
loop response and low dropout voltage make this regulator ideal for
applications where low voltage and good load transient response are
important. Device protection includes current limit, short circuit
protection, and thermal shutdown. The NCP565 is packaged in a 5 pin
D
2
PAK for adjustable voltage version and a 3 pin D
2
PAK for fixed
voltage version.
Features
http://onsemi.com
MARKING
DIAGRAMS
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Ultra Fast Transient Response (t1.0
ms)
Low Ground Current (1.1 mA @ Iload = 1.5 A)
Low Dropout Voltage (0.9 V @ Iload = 1.5 A)
Low Noise (28
mVrms)
0.9 V Reference Voltage
Adjustable Output Voltage from 7.7 V down to 0.9 V
Current Limit Protection (3.5 A)
Thermal Shutdown Protection (155擄C)
Servers
ASIC Power Supplies
Post Regulation for Power Supplies
Constant Current Source
1
2
3
D
2
PAK
CASE 936
FIXED
Tab = Ground
Pin 1. V
in
2. Ground
3. V
out
xxxx
AWLYWW
Typical Applications
1
5
D
2
PAK
CASE 936A
ADJUSTABLE
Tab = Ground
Pin 1. N.C.
2. V
in
3. Ground
4. V
out
5. Adj
xxxx
AWLYWW
xxxx = Specific Device Code
A
= Assembly Location
WL = Wafer Lot
Y
= Year
WW = Work Week
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 9 of this data sheet.
漏
Semiconductor Components Industries, LLC, 2003
1
December, 2003 鈭?Rev. 4
Publication Order Number:
NCP565/D
