MMUN2212LT1 Datasheet

  • MMUN2212LT1

  • Bias Resistor Transistor

  • 12頁

  • ONSEMI

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

MMUN2211LT1 Series
Preferred Devices
Bias Resistor Transistor
NPN Silicon Surface Mount Transistor
with Monolithic Bias Resistor Network
This new series of digital transistors is designed to replace a single
device and its external resistor bias network. The BRT (Bias Resistor
Transistor) contains a single transistor with a monolithic bias network
consisting of two resistors; a series base resistor and a base-emitter
resistor. The BRT eliminates these individual components by
integrating them into a single device. The use of a BRT can reduce
both system cost and board space. The device is housed in the SOT-23
package which is designed for low power surface mount applications.
http://onsemi.com
PIN 3
COLLECTOR
(OUTPUT)
R1
PIN 1
BASE
(INPUT)
R2
鈥?/div>
Simplifies Circuit Design
鈥?/div>
Reduces Board Space and Component Count
鈥?/div>
The SOT-23 package can be soldered using wave or reflow. The
modified gull-winged leads absorb thermal stress during soldering
eliminating the possibility of damage to the die.
鈥?/div>
Available in 8 mm embossed tape and reel. Use the Device
Number to order the 7 inch/3000 unit reel. Replace 鈥淭1鈥?with
鈥淭3鈥?in the Device Number to order the13 inch/10,000 unit reel.
MAXIMUM RATINGS
(T
A
= 25擄C unless otherwise noted)
Rating
Collector-Base Voltage
Collector-Emitter Voltage
Collector Current
Total Power Dissipation @ T
A
= 25擄C
(Note 1) Derate above 25擄C
Symbol
V
CBO
V
CEO
I
C
P
D
Value
50
50
100
*200
1.6
Unit
Vdc
Vdc
mAdc
mW
mW/擄C
PIN 2
EMITTER
(GROUND)
MARKING DIAGRAM
3
1
2
SOT鈭?3
CASE 318
STYLE 6
1
2
A8x = Device Code
x
= (See Table)
3
A8x
ORDERING INFORMATION
Device
MMUN2211LT1
MMUN2212LT1
MMUN2213LT1
Package
SOT鈭?3
SOT鈭?3
SOT鈭?3
SOT鈭?3
SOT鈭?3
SOT鈭?3
SOT鈭?3
SOT鈭?3
SOT鈭?3
SOT鈭?3
SOT鈭?3
SOT鈭?3
SOT鈭?3
Shipping
鈥?/div>
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
3000/Tape & Reel
DEVICE MARKING AND RESISTOR VALUES
Device
MMUN2211LT1
MMUN2212LT1
MMUN2213LT1
MMUN2214LT1
MMUN2215LT1
MMUN2216LT1
MMUN2230LT1
MMUN2231LT1
MMUN2232LT1
MMUN2233LT1
MMUN2234LT1
MMUN2238LT1
MMUN2241LT1
Marking
A8A
A8B
A8C
A8D
A8E
A8F
A8G
A8H
A8J
A8K
A8L
A8R
A8U
R1(K)
10
22
47
10
10
4.7
1.0
2.2
4.7
4.7
22
2.2
100
R2(K)
10
22
47
47
鈭?/div>
鈭?/div>
1.0
2.2
4.7
47
MMUN2214LT1
MMUN2215LT1
MMUN2216LT1
MMUN2230LT1
MMUN2231LT1
MMUN2232LT1
MMUN2233LT1
MMUN2234LT1
MMUN2238LT1
MMUN2241LT1
47
鈭?/div>
鈭?/div>
鈥燜or information on tape and reel specifications,
including part orientation and tape sizes, please
refer to our Tape and Reel Packaging Specification
Brochure, BRD8011/D.
Preferred
devices are recommended choices for future use
and best overall value.
1. Device mounted on a FR-4 glass epoxy printed circuit board using the
minimum recommended footprint.
漏
Semiconductor Components Industries, LLC, 2004
May, 2004 鈭?Rev. 4
Publication Order Number:
MMUN2211LT1/D

MMUN2212LT1 產品屬性

  • 3,000

  • 分離式半導體產品

  • 晶體管(BJT) - 單路﹐預偏壓式

  • -

  • NPN - 預偏壓

  • 100mA

  • 50V

  • 22k

  • 22k

  • 60 @ 5mA，10V

  • 250mV @ 300µA，10mA

  • 500nA

  • -

  • 246mW

  • 表面貼裝

  • TO-236-3，SC-59，SOT-23-3

  • SOT-23-3（TO-236）

  • 帶卷 (TR)

  • MMUN2212LT1OSTR
