IS657B
ISO - LOGIC BUFFER SCHMITT
TRIGGER OPEN COLLECTOR
SIDE DETECTOR
Dimensions in mm
DESCRIPTION
The IS657B is an optically integrated
circuit detector with schmitt trigger open
collector buffer output. It is mounted in a
clear plastic lateral side looking package
which enables these devices to display
superior mechanical resolutions, coupled
characteristics and reliability in a low cost
housing.
4.0
0.3
1.5
4
擄
0.45
4.0
1.5
2.5
0.6
0.8
1.27
17.0
7.0
4
擄
3.0
R 0.9
2.0
1.5
0.4
0.2
FEATURES
1.27
8
擄
18.0
1.27
1.27
8
擄
l
l
l
l
l
l
l
Built-in Schmitt trigger circuit
High level output at incident light
Open collector output
Lateral Side Looking Plastic Package
High Sensitivity (E
V
= 35 lx at 25擄C)
LSTTL and TTL Compatible output
Supply voltage V
CC
-0.5 to + 35 volts
1
2
3
APPLICATIONS
l
l
l
l
Voltage Regulator
Floppy disk drives
Copiers, Printers,Facsimilies
VCR's, Cassette tape recorders
Automatic vending machines
3 V
CC
2 Out
1 G
ND
Amp
ISOCOM COMPONENTS LTD
Unit 25B, Park View Road West,
Park View Industrial Estate, Brenda Road
Hartlepool, Cleveland, TS25 1YD
Tel: (01429) 863609 Fax :(01429) 863581
7/12/00
ISOCOM INC
1024 S. Greenville Ave, Suite 240,
Allen, TX 75002 USA
Tel: (214) 495-0755 Fax: (214) 495-0901
e-mail info@isocom.com
http://www.isocom.com
DB92127-AAS/A3
1
2
3
