IRL5602STRR Datasheet

  • IRL5602STRR

  • TRANSISTOR | MOSFET | P-CHANNEL | 20V V(BR)DSS | 24A I(D) | ...

  • 8頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

PD- 91888
IRL5602S
HEXFET
廬
Power MOSFET
l
l
l
l
l
l
Advanced Process Technology
Dynamic dv/dt Rating
175擄C Operating Temperature
P-Channel
Fast Switching
Fully Avalanche Rated
D
V
DSS
= -20V
G
S
R
DS(on)
= 0.042W
I
D
= -24A
Description
Fifth Generation HEXFETs from International Rectifier utilize advanced
processing techniques to achieve extremely low on-resistance per silicon area.
This benefit, combined with the fast switching speed and ruggedized device
design that HEXFET Power MOSFETs are well known for, provides the
designer with an extremely efficient and reliable device for use in a wide variety
of applications.
The D
2
Pak is a surface mount power package capable of accommodating die
sizes up to HEX-4. It provides the highest power capability and the lowest
possible on-resistance in any existing surface mount package. The D
2
Pak is
suitable for high current applications because of its low internal connection
resistance and can dissipate up to 2.0W in a typical surface mount application.
D
2
Pak
Absolute Maximum Ratings
Parameter
I
D
@ T
C
= 25擄C
I
D
@ T
C
= 100擄C
I
DM
P
D
@T
C
= 25擄C
V
GS
E
AS
I
AR
E
AR
dv/dt
T
J
T
STG
Continuous Drain Current, V
GS
@ -4.5V
Continuous Drain Current, V
GS
@ -4.5V
Pulsed Drain Current
聛
Power Dissipation
Linear Derating Factor
Gate-to-Source Voltage
Single Pulse Avalanche Energy聜
Avalanche Current聛
Repetitive Avalanche Energy聛
Peak Diode Recovery dv/dt
聝
Operating Junction and
Storage Temperature Range
Soldering Temperature, for 10 seconds
Max.
-24
-17
-96
75
0.5
鹵 8.0
290
-12
7.5
-0.81
-55 to + 175
300 (1.6mm from case )
Units
A
W
W/擄C
V
mJ
A
mJ
V/ns
擄C
Thermal Resistance
Parameter
R
qJC
R
qJA
Junction-to-Case
Junction-to-Ambient ( PCB Mounted,steady-state)**
Typ.
鈥撯€撯€?/div>
鈥撯€撯€?/div>
Max.
2.0
40
Units
擄C/W
www.irf.com
1
5/11/99

IRL5602STRR 產品屬性

  • 800

  • 分離式半導體產品

  • FET - 單

  • HEXFET®

  • MOSFET P 通道，金屬氧化物

  • 邏輯電平門

  • 20V

  • 24A

  • 42 毫歐 @ 12A，4.5V

  • 1V @ 250µA

  • 44nC @ 4.5V

  • 1460pF @ 15V

  • 75W

  • 表面貼裝

  • TO-263-3，D²Pak（2 引線+接片），TO-263AB

  • D2PAK

  • 帶卷 (TR)
