IRL2505PBF Datasheet

  • IRL2505PBF

  • HEXFET Power MOSFET

  • 8頁

  • IRF

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

PD -95622
Logic-Level Gate Drive
l
Advanced Process Technology
l
Ultra Low On-Resistance
l
Dynamic dv/dt Rating
l
175擄C Operating Temperature
l
Fast Switching
l
Fully Avalanche Rated
l
Lead-Free
Description
l
HEXFET
廬
Power MOSFET
D
IRL2505PbF
V
DSS
= 55V
R
DS(on)
= 0.008鈩?/div>
G
I
D
= 104A
聟
S
Fifth Generation HEXFETs from International Rectifier utilize
advanced processing techniques to achieve extremely low
on-resistance per silicon area. This benefit, combined with
the fast switching speed and ruggedized device design that
HEXFET Power MOSFETs are well known for, provides the
designer with an extremely efficient and reliable device for
use in a wide variety of applications.
The TO-220 is universally preferred for all commercial-
Industrial applications at power dissipation levels to
approximately 50 watts. The low thermal resistance and
low package cost of the TO-220 contribute to its wide
acceptance throughout the industry.
TO-220AB
Absolute Maximum Ratings
Parameter
I
D
@ T
C
= 25擄C
I
D
@ T
C
= 100擄C
I
DM
P
D
@T
C
= 25擄C
V
GS
E
AS
I
AR
E
AR
dv/dt
T
J
T
STG
Continuous Drain Current, V
GS
@ 10V
Continuous Drain Current, V
GS
@ 10V
Pulsed Drain Current
聛
Power Dissipation
Linear Derating Factor
Gate-to-Source Voltage
Single Pulse Avalanche Energy
聜
Avalanche Current
聛
Repetitive Avalanche Energy
聛
Peak Diode Recovery dv/dt
聝
Operating Junction and
Storage Temperature Range
Soldering Temperature, for 10 seconds
Mounting torque, 6-32 or M3 srew
Max.
104
聟
74
360
200
1.3
鹵 16
500
54
20
5.0
55 to + 175
300 (1.6mm from case )
10 lbf鈥n (1.1N鈥)
Units
A
W
W/擄C
V
mJ
A
mJ
V/ns
擄C
Thermal Resistance
Parameter
R
胃JC
R
胃CS
R
胃JA
Junction-to-Case
Case-to-Sink, Flat, Greased Surface
Juction-to-Ambient
Typ.
鈥撯€撯€?/div>
0.50
鈥撯€撯€?/div>
Max.
0.75
鈥撯€撯€?/div>
62
Units
擄C/W
www.irf.com
1
8/3/04

IRL2505PBF 產品屬性

  • 50

  • 分離式半導體產品

  • FET - 單

  • HEXFET®

  • MOSFET N 通道，金屬氧化物

  • 邏輯電平門

  • 55V

  • 104A

  • 8 毫歐 @ 54A，10V

  • 2V @ 250µA

  • 130nC @ 5V

  • 5000pF @ 25V

  • 200W

  • 通孔

  • TO-220-3

  • TO-220AB

  • 管件

  • *IRL2505PBF
