ILA8362W Datasheet

  • ILA8362W

  • SINGLE-CHIP TV PROCESSOR IC FOR VISION AND SOUND IF PROCESSI...

  • 6頁

  • INTEGRAL

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

ILA8362W
S
INGLE
-
CHIP
TV
PROCESSOR
IC
FOR VISION AND SOUND
IF
PROCESSING
,
VIDEO AND SYNCHRONIZATION FOR B
/
W
TV
IC DESCRIPTION
ILA8362W is intended for b/w TV receiver and contain functional units for video and
sound IF signals, line and frame synchronization , output Y-signal.
IC FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
circuit for processing Vision IF (positive and negative modulation).
FM sound demodulator (4.5-6.5
袦Hz).
Addition inputs for A/V (external and internal video inputs, internal and external audio inputs).
Embedded delay line for brightness signal.
control IC for output Y-signal and external Y-input and possibility of a direct information display on screen
(OSD
mode).
Line synchronisation with two control circuits and a generator (adjustment is not needed).
IC for frame divider and preamplifier of frame scanning.
Low power consumption (500 mW).
Minimum quantity of external parts.
Only one adjustment is required (IF demodulator).
Block diagram of TV signal processor ILA 8362 W
50
51
6
1
40
41
10
11
39 38
1
36
5
SOUND
PREAMPL.
VOLUME
COMTROL
SOUND SWITCH
SYNC
SEPARATOR
PHASE 1 DET.
LINE
GENERATOR
PHASE 2 DET.
HORIZ. SHIFT
lINE SCANNING
OUTPUT
37
43
49
47
48
AGC
AGC TUNER
SOUND LIMITER
DEMODULATOR
FRAME SYNCH
SEPARATOR
FRAME DIVIDER
CIRCUIT
fRAME
SCANNING
OUTPUT
42
44
12
45
46
2
3
IFAMPLIF.
DEMODULATOR
FILTOR TUNING
CIRCUIT
小嘯袝袦袗
袪袝袚校袥袠袪袨袙-袣袠
效衼孝袣袨小孝袠
Y-袙嘯袨袛蝎
小嘯袝袦袗
袣袨袦袦校孝袗笑袠袠
14
32
21
9
PAFTC
CIRCUIT
VIDEO
AMPLIFIER
QWARZ
GENERATOR
袙蝎嘯袨袛袧袨袡
Y
袣袗小袣袗袛
18
17
4
VIDEO SIGNAL
SWITCHING CIRCUIT
LIMITER OF WHITE
CONTRAST
ADGUSTMENT
VIDEO IDENTIF.
CIRCUIT
INPUT SWITCH
33
8
52
15
13
7
16
35
ILA8362W incorporate advantages of bipolar and MOS technologies, fulfill almost
all low signal functions of w/b TV receiver. To assemble b/w TV-set it鈥檚 necessary to add
tuner, output stages for video, audio, frame and line scannig.
1
