IL350/351/358/359
High Performance Linear Optocoupler
for Optical DAA in Telecommunications
FEATURES
鈥?2.0 mm High SMT Package
鈥?High Sensitivity (K1) at Low Operating
LED Current
鈥?Couples AC and DC Signals
鈥?Low Input-Output Capacitance
鈥?Isolation Voltage, 3000 V
RMS
鈥?Low Distortion
APPLICATIONS
鈥?Optical DAA for V.34 FAX/Modem
PCMCIA Cards
鈥?Digital Telephone Line Isolation
DESCRIPTION
The IL350/1/8/9 family of Linear Optocoupler
consist of an IRLED optically coupled to two
photodiodes. The emitter mechanically faces
both diodes enabling them to receive approxi-
mately an equal amount of infrared light. The
diodes produce a proportional amount of pho-
tocurrents. The ratio of the photocurrents stays
constant with high accuracy when either the
LED current changes or the ambient tempera-
ture changes. Thus one can control the output
diode current optically by controlling the input
photodiode current.
The IL350/1/8/9 optocouplers can be used
with the aid of operational ampli鏗乪rs in closed
loop conditions to achieve highly linear and
electrically isolated AC and or DC signal
ampli鏗乪rs.
.043 (1.08)
.033 (.83)
.050
(1.25)
Typ.
Dimensions in Inches (mm)
K 1
.336 (8.4)
鹵.010
(鹵.25)
.225 (5.6)
.215 (5.4)
A 2
K 3
A 4
.230 (5.75)
.220 (5.5)
.015 (.375)
鹵.002
(鹵.050)
.042 (1.05)
Ref.
.091 (2.3)
.083 (2.1)
.016
(.41)
Typ.
10擄 Typ.
.291 (7.39)
鹵010
(.254)
.015 (.375)
鹵.002
(.050)
40擄
3擄鈥?擄
8 K
7 A
6 N.C
5 N.C
Pin
One
ID
.006 (.15)
Typ.
Absolute Maximum Ratings
Maximum Ratings
Emitter
Reverse Voltage..........................................................................................3.0 V
Forward Current ...................................................................................... 30 mA
Surge Current, Pulse Width <10
碌s
....................................................... 150 mA
Power Dissipation,
T
A
=25擄C .................................................................150 mW
Derate Linearly from 25擄C .................................................................2.0 mW/擄C
Detector
Reverse Voltage ..........................................................................................15 V
Power Dissipation ....................................................................................50 mW
Derate Linearly from 25擄C ...............................................................0.65 mW/擄C
Junction Temperature ...............................................................................100擄C
Coupler
Isolation Test Voltage, t=1.0 sec. ..................................................... 3000 V
RMS
Total Package Power Dissipation .........................................................250 mW
Derate Linearly from 25擄C .................................................................2.8 mW/擄C
Storage Temperature Range....................................................鈥?0擄C to +150擄C
Operating Temperature...............................................................................75擄C
Lead Soldering Time at 260擄C ............................................................... 10 sec.
Isolation Resistance
V
IO
=500 V,
T
A
=25
擄
C ...........................................................................
鈮?/div>
10
12
鈩?/div>
V
IO
=500 V,
T
A
=100
擄
C .........................................................................
鈮?/div>
10
11
鈩?/div>
錚?/div>
2000 In鏗乶eon Technologies Corp. 鈥?Optoelectronics Division 鈥?San Jose, CA
www.in鏗乶eon.com/opto 鈥?1-888-In鏗乶eon (1-888-463-4636)
OSRAM Opto Semiconductors GmbH & Co. OHG 鈥?Regensburg, Germany
www.osram-os.com 鈥?+49-941-202-7178
1
March 8, 2000-01
IL351 產(chǎn)品屬性
Vishay
高線性光耦合器
1 Channel
AC/DC
2.1 V
3 V
30 mA
250 mW
+ 75 C
0 C
SOP-8
Tube
0.5 %
10 mA
3000 Vrms
350 ns
Photodiode
DC
720
