IDTQS74FCT2157ATS1 Datasheet

  • IDTQS74FCT2157ATS1

  • 2-Input Digital Multiplexer

  • 119.45KB

  • 6頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

IDTQS74FCT2157AT/CT
HIGH-SPEED CMOS QUAD 2-INPUT MULTIPLEXER
INDUSTRIAL TEMPERATURE RANGE
HIGH-SPEED CMOS
QUAD 2-INPUT
MULTIPLEXER
FEATURES:
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
鈭?/div>
CMOS power levels: <7.5mW static
Undershoot clamp diodes on all inputs
True TTL input and output compatibility
Ground bounce controlled outputs
Reduced output swing of 0 to 3.5V
Built-in 25鈩?series resistor outputs reduce reflection and other
system noise
A and C speed grades with 4.3ns for C
I
OL
= 12mA
Available in SOIC, QSOP, and S1 packages
IDTQS74FCT2157AT/CT
DESCRIPTION:
The IDTQS74FCT2157T is a high-speed CMOS TTL-compatible,
quad, 2-input multiplexer with a 25鈩?resistor output, useful for driving
transmission lines and reducing system noise. All inputs have clamp diodes
for undershoot noise suppression. All outputs have ground bounce
suppression. Outputs will not load an active bus when Vcc is removed from
the device.
FUNCTIONAL BLOCK DIAGRAM
E
15
S
1
I0A
2
I1A
3
I0B
5
I1B
6
I0C
11
I1C
10
I0D
14
I1D
13
25
鈩?/div>
4
7
25
鈩?/div>
9
25
鈩?/div>
12
25
鈩?/div>
YA
YB
YC
YD
INDUSTRIAL TEMPERATURE RANGE
1
c
2001 Integrated Device Technology, Inc.
JANUARY 2001
DSC-5401/2
