Modulation Current and Bias Current Monitor
Duty Ratio Monitor
Duty Ratio Control
Single Power Supply: -5.2V
Separated Peak Current and Bias Current Outputs
Small Package: SSOP-16
(VDD = 0V)
Symbol
Tstg
TOP
VSS
DIN, DIN, CIN
VIP
VIB
Ratings
-40 to +125
-40 to +85
-7.0 to 0
VSS to VDD
VSS -2.0 to VSS +2.1
VSS -2.0 to VSS +2.1
Unit
擄C
擄C
V
V
V
V
ABSOLUTE MAXIMUM RATINGS
Parameter
Storage Temperature
Operating Temperature*
Supply Voltage
Input Voltage
Peak Current Control Voltage
Bias Current Control Voltage
(*) Lower limit temperature corresponds to the ambient temperature and higher limit temperature
corresponds to the case (the bottom of the case) temperature.
RECOMMENDED OPERATING CONDITIONS
Parameter
Power Supply Voltage
Data & Clock Input
Peak Current Control Voltage
Bias Current Control Voltage
Output Shutdown Control Voltage
Selector Control Voltage
Symbol
VSS
VIH
VIL
VIP
VIB
VSD
VSE
Output enable
Output disable (Shutdown)
D-F/F active
D-F/F inactive
Test Conditions
Limit
Min. Typ. Max.
-5.72 -5.2 -4.94
-1.0
-1.9
VSS
VSS
-1.9
-1.0
-
-
-0.9
-1.7
-
-
-1.7
-0.9
VDD
Open
-0.7
-1.6
VSS
+2.1
VSS
+2.1
-1.6
-0.7
-
-
(VDD = 0V)
Unit
V
V
V
V
V
V
V
V
-
Edition 1.2
June 2000
