FMG2G400LS60
IGBT
FMG2G400LS60
Molding Type Module
General Description
Fairchild IGBT Power Module provides low conduction as
well as short circuit ruggedness. It鈥檚 designed for the
applications such as welder.
Features
鈥?Short Circuit Rated Time; 10us @ T
C
=100擄C, V
GE
= 15V
鈥?Low Saturation Voltage : V
CE
(sat) = 1.4 V @ I
C
= 400A
鈥?High Input Impedance
鈥?Fast & Soft Anti-Parallel FWD
鈥?UL Certified No.E209204
Application
鈥?AC/ DC Welder
Package Code : 7PM-IA
E1/C2
C1
E2
G1
E1
G2
E2
Internal Circuit Diagram
Absolute Maximum Ratings
Symbol
V
CES
V
GES
I
C
I
CM (1)
I
F
I
FM
P
D
T
SC
T
J
T
STG
V
ISO
Mounting Torque
T
C
= 25擄C unless otherwise noted
Description
Collector-Emitter Voltage
Gate-Emitter Voltage
Collector Current
Pulsed Collector Current
Diode Continuous Forward Current
Diode Maximum Forward Current
Maximum Power Dissipation
Short Circuit Withstand Time
Operating Junction Temperature
Storage Temperature Range
Isolation Voltage
Power Terminal Screw : M6
Mounting Screw : M6
@ T
C
= 25擄C
@ T
C
= 100擄C
FMG2G400LS60
600
鹵 20
400
800
400
800
1136
10
-40 to +150
-40 to +125
2500
4.0
4.0
Units
V
V
A
A
A
A
W
us
擄C
擄C
V
N.m
N.m
@ AC 1minute
Notes :
(1) Repetitive rating : Pulse width limited by max. junction temperature
漏2004 Fairchild Semiconductor Corporation
FMG2G400LS60 Rev. A
