FBE22-06N1 Datasheet

  • FBE22-06N1

  • Fast Single Phase Rectifier Bridge

  • 2頁

  • IXYS   IXYS

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

Advanced Technical Information
Fast Single Phase
Rectifier Bridge
in ISOPLUS i4-PAC
TM
FBE 22-06N1
V
RRM
= 600 V
I
D(AV)M
= 20 A
t
rr
= 80 ns
1
5
Input Rectifier Bridge
Symbol
V
RRM
I
FAV
I
D(AV)M
I
FSM
E
AS
P
tot
T
C
= 90擄C; sine 180擄 (per diode)
T
C
= 90擄C
T
VJ
= 25擄C; t = 10 ms; sine 50 Hz
I
AS
= 0.9 A; L
AS
=180 碌H; T
C
= 25擄C; non repetitive
T
C
= 25擄C
(per diode)
Conditions
Maximum Ratings
600
10
20
40
0.1
35
V
A
A
A
mJ
W
Features
鈥?HiPerFREDTM Epitaxial Diodes
- fast and soft reverse recovery 鈥?/div>
low switching losses
- avalanche rated
- low leakage current
鈥?ISOPLUS i4-PACTM package
- isolated back surface
- enlarged creepage towards heatsink
- application friendly pinout
- high reliability
- industry standard outline
Symbol
Conditions
Characteristic Values
(T
VJ
= 25擄C, unless otherwise specified)
min.
typ. max.
2.0
1.5
0.1
11
80
2.2
0.06
V
V
mA
mA
A
ns
3.5 K/W
Applications
鈥?high frequency rectifiers, output
rectifiers of switched mode power
supplies
鈥?single phase mains rectifiers with
minimized electromagnetic emissions
鈥?power factor correction in conjunction
with boost chopper (FID.../FMD... type)
V
F
I
R
I
RM
t
rr
R
thJC
I
F
= 15 A; T
VJ
= 25擄C
T
VJ
= 125擄C
V
R
= V
RRM
; T
VJ
= 25擄C
T
VJ
= 125擄C
I
F
= 10 A; di
F
/dt = -400 A/碌s; T
VJ
= 125擄C
V
R
= 300 V
(per diode)
Data according to IEC 60747 and refer to a single diode unless otherwise stated.
IXYS reserves the right to change limits, test conditions and dimensions.
漏 2000 IXYS All rights reserved
1-2
030

FBE22-06N1 產品屬性

  • 25

  • 分離式半導體產品

  • 橋式整流器

  • -

  • 600V

  • 20A

  • 單相

  • 快速恢復 = 200mA（Io）

  • 80ns

  • 通孔

  • i4-Pac?-5

  • 管件

  • ISOPLUS i4-PAC?
