AS2840AU Datasheet

  • AS2840AU

  • Analog IC

  • 4頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

AS2840
4A Low Dropout Voltage Regulator
Adjustable & Fixed 3.3V
FEATURES
鈥?/div>
Adjustable Output Down To 1.25V Or Fixed 3.3V
鈥?/div>
Output Current Of 4A
鈥?/div>
Low Dropout Voltage
鈥?/div>
Extremely Tight Load And Line Regulation
鈥?/div>
Current & Thermal Limiting
鈥?/div>
Standard 3-Terminal Low Cost TO-220
APPLICATIONS
鈥?/div>
Powering Intel Pentium錚?/div>
碌P
from +5V Supplies
鈥?/div>
Power PC錚?Supplies
鈥?/div>
SMPS Post-Regulator
鈥?/div>
High Efficiency 鈥淕reen鈥?Computer Systems
鈥?/div>
High Efficiency Linear Power Supplies
鈥?/div>
Portable Instrumentation
鈥?/div>
Constant Current Regulators
鈥?/div>
Adjustable Power Supplies
鈥?/div>
Battery Charger
PRODUCT DESCRIPTION
The AS2840 is a low power 4A Adjustable Voltage Regulator that is very easy to use. It requires only 2 external resistors to set the
output voltage. This device is an excellent choice for use in Powering Intel錚?Microprocessor to convert from +5V to 3.3V supplies
and as a post regulator for switching supplies applications. The AS2840 features low dropout of a maximum 1.3 volts.
The AS2840 offers over-current limit and full protection against reversed input polarity, reversed load insertion, over temperature
operation, and positive and negative transient voltage. On-Chip trimming adjusts the reference voltage to 1%. The I
Q
of this device
flows in to the load, which increases the efficiency.
The AS2840 is offered in a 3-pin TO-220 package compatible with other 3 terminal regulators. For a 3A low dropout regulator refer
to the AS2830 data sheet.
ORDERING INFORMATION
TO-220
3-PIN
AS2840AU
Consult with factory for other fixed output voltages.
PIN CONNECTIONS
TO-220-3 (U)
AS2840
1
2
3
ADJ/GND V
OUT
V
IN
Front View
Rev. 10/11/00
