AS2850
5A Low Dropout Voltage Regulator
Adjustable & Fixed Output,
Fast Response
FEATURES
鈥?/div>
Adjustable Output Down To 1.2V
鈥?/div>
Fixed Output Voltages 1.5V, 2.5V, 3.3V & 5.0V
鈥?/div>
Output Current Of 5A
鈥?/div>
Low Dropout Voltage 1.1V Typ @ 5A.
鈥?/div>
Extremely Tight Load And Line Regulation
鈥?/div>
Current & Thermal Limiting
鈥?/div>
Standard 3-Terminal Low Cost TO-220 & TO-263
鈥?/div>
Similar To Industry Standard LT1085/LT1585
APPLICATIONS
鈥?/div>
Powering VGA & Sound Card
鈥?/div>
Power PC餂汼upplies
鈥?/div>
SMPS Post-Regulator
鈥?/div>
High Efficiency 鈥淕reen鈥?Computer Systems
鈥?/div>
High Efficiency Linear Power Supplies
鈥?/div>
Portable Instrumentation
鈥?/div>
Constant Current Regulators
鈥?/div>
Adjustable Power Supplies
鈥?/div>
Battery charger
PRODUCT DESCRIPTION
The AS2850 are low power 5A adjustable and fixed voltage regulators that are very easy to use. It requires only 2 external resistors to
set the output voltage for adjustable version. The AS2850 are designed for low voltage applications that offers lower dropout voltage
and faster transient response. This device is an excellent choice for use in powering low voltage microprocessor that require a lower
dropout, faster transient response to regulate from +2.5V to 3.8V supplies and as a post regulator for switching supplies applications.
The AS2850 features low dropout of a maximum 1.2 volts.
The AS2850 offers full protection against over-current faults, reversed input polarity, reversed load insertion, and positive and
negative transient voltage. On-Chip trimming adjusts the reference voltage to 1%. The I
Q
of this device flows into the load, which
increases efficiency.
The AS2850 are offered in a 3-pin TO-220 and TO-263 package compatible with other 3 terminal regulators. For a 8A low dropout
regulator refer to the AS2880 data sheet.
ORDERING INFORMATION
TO-220
3-PIN
AS2850YU-X
DD PLASTIC
3-PIN
AS2850YT-X
PIN CONNECTIONS
X= Output Voltage (i.e. 1.5 for 1.5V, 2.5 for 2.5V etc.)
Y= Output Tolerance, A for 1%
Blank for 2%
Consult factory for other fixed voltages.
TO-263-3 (T)
3
V
IN
V
OUT
ADJ/GND
Front View
TO-220-3 (U)
3
V
IN
V
OUT
ADJ/GND
AS2850
2
1
AS2580
2
1
Top View
Rev. 10/11/00
