28C16A
16K (2K x 8) CMOS EEPROM
FEATURES
鈥?Fast Read Access Time鈥?50 ns
鈥?CMOS Technology for Low Power Dissipation
- 30 mA Active
- 100
碌
A Standby
鈥?Fast Byte Write Time鈥?00
碌
s or 1 ms
鈥?Data Retention >200 years
鈥?High Endurance - Minimum 10
4
Erase/Write Cycles
鈥?Automatic Write Operation
- Internal Control Timer
- Auto-Clear Before Write Operation
- On-Chip Address and Data Latches
鈥?Data polling
鈥?Chip Clear Operation
鈥?Enhanced Data Protection
- V
CC
Detector
- Pulse Filter
- Write Inhibit
鈥?Electronic Signature for Device Identi鏗乧ation
鈥?5-Volt-Only Operation
鈥?Organized 2Kx8 JEDEC Standard Pinout
鈥?24-pin Dual-In-Line Package
鈥?32-pin PLCC Package
鈥?Available for Extended Temperature Ranges:
- Commercial: 0藲C to +70藲C
- Industrial: -40藲C to +85藲C
PACKAGE TYPES
32
Vcc
31
WE
18
19
4
A7
3
NC
2
NC
1
NU
鈥?Pin 1 indicator on PLCC on top of package
BLOCK DIAGRAM
I/O0
I/O7
V
SS
V
CC
CE
OE
WE
Data Protection
Circuitry
Chip Enable/
Output Enable
Control Logic
Auto Erase/Write
Timing
Data
Poll
Program Voltage
Generation
A0
DESCRIPTION
The Microchip Technology Inc. 28C16A is a CMOS 16K
non-volatile electrically Erasable PROM. The 28C16A
is accessed like a static RAM for the read or write
cycles without the need of external components. Dur-
ing a 鈥渂yte write鈥? the address and data are latched
internally, freeing the microprocessor address and data
bus for other operations. Following the initiation of write
cycle, the device will go to a busy state and automati-
cally clear and write the latched data using an internal
control timer. To determine when a write cycle is com-
plete, the 28C16A uses Data polling. Data polling
allows the user to read the location last written to when
the write operation is complete. CMOS design and pro-
cessing enables this part to be used in systems where
reduced power consumption and reliability are
required. A complete family of packages is offered to
provide the utmost 鏗俥xibility in applications.
A10
L
a
t
c
h
e
s
Y
Decoder
X
Decoder
漏
1998 Microchip Technology Inc.
