ZXTD3M832
MPPS
TM
Miniature Package Power Solutions
DUAL 40V PNP LOW SATURATION TRANSISTOR
SUMMARY
PNP
V
CEO
= -40V; R
SAT
= 104m ; I
C
= -3A
DESCRIPTION
Packaged in the new
innovative 3mm x 2mm MLP (Micro Leaded
Package)
outline, these new 4
th
generation low saturation dual PNP transistors offer
extremely low on state losses making them ideal for use in DC-DC circuits and
various driving and power management functions.
Additionally users gain several other
key benefits:
Performance capability equivalent to much larger packages
Improved circuit efficiency & power levels
PCB area and device placement savings
Lower Package Height (0.9mm nom)
Reduced component count
MLP832
FEATURES
鈥?/div>
Low Equivalent On Resistance
鈥?/div>
Extremely Low Saturation Voltage
(-220mV max @1A)
鈥?/div>
h
FE
specified up to -3A
鈥?/div>
I
C
= -3A Continuous Collector Current
鈥?/div>
3mm x 2mm MLP
APPLICATIONS
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
DC - DC Converters
Charging circuits
Power switches
Motor control
CCFL Backlighting
ORDERING INFORMATION
DEVICE
ZXTD3M832TA
ZXTD3M832TC
REEL
SIZE
7鈥?/div>
13鈥?/div>
TAPE
WIDTH
8mm
8mm
QUANTITY
PER REEL
3000
10000
DEVICE MARKING
鈥?/div>
D33
Underside view
ISSUE 1 - JUNE 2003
1
SEMICONDUCTORS
