ZXSDS2M832 Datasheet

  • ZXSDS2M832

  • 6頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

ZXSDS2M832
MPPS鈩?Miniature Package Power Solutions
DUAL 60V, 1.65A SCHOTTKY DIODE COMBINATION
SUMMARY
Schottky Diode - V
R
= 60V; V
F
= 600mV(@1A); IC=1.65A
DESCRIPTION
Packaged in the new innovative 3x2 MLP (Micro Leaded Package) outline, this
combination dual comprises two 60V 0.9A Schottky barrier diodes. This excellent
combination provides users with highly efficient performance in applications
including DC-DC converters and charging circuits.
Additionally users gain several other
key benefits:
Performance capability equivalent to much larger packages
Improved circuit efficiency & power levels
PCB area and device placement savings
Lower Package Height (0.9mm nom)
Reduced component count
MLP832
FEATURES
鈥?/div>
Extremely Low V
F
, fast switching Schottky
鈥?/div>
I
F
= 1.65A Continuous Forward Current
鈥?/div>
3mm x 2mm MLP
APPLICATIONS
鈥?/div>
DC-DC Converters
鈥?/div>
DC-DC Modules
鈥?/div>
Mosfet gate drive circuits
鈥?/div>
Charging circuits
鈥?/div>
Mobile Phones
鈥?/div>
Motor Control
PINOUT
ORDERING INFORMATION
DEVICE
ZXSDS2M832TA
ZXSDS2M832TC
REEL
SIZE
7鈥?/div>
13鈥?/div>
TAPE
WIDTH
8mm
8mm
QUANTITY
PER REEL
3000 units
10000 units
Bottom View
DEVICE MARKING
鈥?/div>
DS2
ISSUE 2 June 2003
1
SEMICONDUCTORS
