ZXMC3AM832(2) Datasheet

  • ZXMC3AM832(2)

  • 313.09KB

  • 10頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規(guī)格書

PDF預覽

ZXMC3AM832
MPPS鈩?Miniature Package Power Solutions
COMPLEMENTARY 30V ENHANCEMENT MODE MOSFET
SUMMARY
N-Channel V
(BR)DSS
= 30V; R
DS(ON)
= 0.12 ; I
D
= 3.7A
P-Channel V
(BR)DSS
= -30V; R
DS(ON)
= 0.21 ; I
D
= -2.7A
DESCRIPTION
Packaged in the new innovative 3mm x 2mm MLP(Micro Leaded Package)
outline this dual 30V N channel Trench MOSFET utilizes a unique structure
combining the benefits of Low on-resistance with fast switching speed. This
makes them ideal for high efficiency, low voltage power management
applications. Users will also gain several other
key benefits:
Performance capability equivalent to much larger packages
Improved circuit efficiency & power levels
PCB area and device placement savings
Reduced component count
3mm x 2mm Dual Die MLP
FEATURES
鈥?/div>
Low On - Resistance
鈥?/div>
Fast switching speed
鈥?/div>
Low threshold
鈥?/div>
Low gate drive
鈥?/div>
3mm x 2mm MLP
APPLICATIONS
鈥?/div>
MOSFET Gate Drive
鈥?/div>
LCD Backlight Inverters
鈥?/div>
Motor Control
PINOUT
5
6
7
8
ORDERING INFORMATION
DEVICE
ZXMC3AM832TA
ZXMC3AM832TC
REEL
7
鈥欌€?/div>
13鈥欌€?/div>
TAPE
WIDTH
8mm
8mm
QUANTITY
PER REEL
3000 units
10000 units
4
3
2
1
3 x 2 Dual MLP
DEVICE MARKING
C01
underside view
PROVISIONAL ISSUE D - JULY 2002
1
