ZXFBF08
8 Channel Buffer Device
DEVICE DESCRIPTION
The ZXFBF08 is a low cost, high slew rate, octal buffer
amplifier. Built using the Zetex CA700 technology, this
buffer has a small signal bandwidth of greater than
100MHz and a 1 volt pk-pk bandwidth of greater than
20 MHz. Each channel draws only 1.9mA. The device
operates from a 鹵5 volt supply, which makes it ideal in
a majority of applications.
This space saving buffer may be used in a wide variety
of applications such as, video switching matrix,
multi-channel instrumentation equipment, and A/D
input buffer, etc.
FEATURES AND BENEFITS
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
8 Buffers per package
100MHz bandwidth
Low cost
Low supply current (1.9mA per buffer)
No thermal runaway
20 pin SOIC package
APPLICATIONS
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Video Switching Matrix input buffer
Instrumentation
Multi-channel A/D input buffer
Multi-isolation buffer
PART
NUMBER
ZXFBF08W20
PACKAGE
SOIC20W
PART MARK
ZXFBF08
ORDERING INFORMATION
PART NUMBER
ZXFBF08W20TC
CONTAINER
Reel 13鈥?/div>
INCREMENT
1000
RELATED PRODUCTS
ZXFBF04 4 Channel Buffer
ZXFBF05
4 Channel Buffer with high capacitance
drive
CONNECTION DIAGRAM
ZXFBF25 4 Channel Buffer with output enable
OUT1
1
2
3
4
5
6
7
8
9
10
20
19
18
17
16
15
14
13
12
11
OUT8
IN1
V-
OUT2
IN2
OUT3
IN3
V-
OUT4
IN4
IN8
V+
OUT7
IN7
OUT6
IN6
V+
OUT5
IN5
ISSUE 2 - OCTOBER 2000
1
