SOT89 P-CHANNEL ENHANCEMENT
MODE VERTICAL DMOS FET
ISSUE 1 - NOVEMBER 1998
FEATURES
*
240 Volt V
DS
*
R
DS(on)
= 8.8鈩?typical at V
GS
=-3.5V
*
Low threshold and Fast switching
APPLICATIONS
*
Electronic hook switches
*
Telecoms and Battery powered equipment
COMPLEMENTARY TYPE -
PARTMARKING DETAIL -
ZVN4424Z
24P
ZVP4424Z
D
S
D
G
ABSOLUTE MAXIMUM RATINGS.
PARAMETER
Drain-Source Voltage
Continuous Drain Current at T
amb
=25擄C
Pulsed Drain Current
Gate Source Voltage
Power Dissipation at T
amb
=25擄C
Operating and Storage Temperature Range
SYMBOL
V
DS
I
D
I
DM
V
GS
P
tot
T
j
:T
stg
VALUE
-240
-200
-1.0
鹵
40
1鈥?/div>
-55 to +150
UNIT
V
mA
A
V
W
擄C
鈥?recommended P
tot
calculated using FR4 measuring 15x15x0.6mm
Refer to the handling instructions for soldering surface mount components.
