Super323鈩?SOT323 PNP SILICON POWER

鈩?/div>

(SWITCHING) TRANSISTOR

ISSUE 1 - SEPTEMBER 1998

FEATURES

ZUMT717

500mW POWER DISSIPATION

CONT 1.5A

3A Peak Pulse Current

Excellent H

Characteristics Up To 3A (pulsed)

Extremely Low Saturation Voltage

Extremely Low Equivalent On Resistance;

CE(sat)

APPLICATIONS

Negative boost functions in DC-DC converters

Supply line switching in mobile phones and pagers

Motor drivers in camcorders and mini disk players

DEVICE TYPE

ZUMT717

COMPLEMENT

ZUMT617

PARTMARKING

T71

CE(sat)

150m鈩?at 1.25A

ABSOLUTE MAXIMUM RATINGS.

PARAMETER

Collector-Base Voltage

Collector-Emitter Voltage

Emitter-Base Voltage

Peak Pulse Current**

Continuous Collector Current

Base Current

Power Dissipation at T

amb

=25擄C*

SYMBOL

CBO

CEO

EBO

tot

VALUE

-12

-5

-3

-1.25

-200

385 鈥?/div>

500 鈥?/div>

-55 to +150

UNIT

Operating and Storage Temperature T

stg

Range

擄C

鈥?Recommended P

tot

calculated using FR4 measuring 10 x 8 x 0.6mm (still air).

鈥?Maximum power dissipation is calculated assuming that the device is mounted on FR4

size 25x25x0.6mm and using comparable measurement methods adopted by other suppliers.
