NPN SILICON PLANAR MEDIUM POWER

HIGH GAIN TRANSISTOR

ISSUE 3 聳 JANUARY 1995

FEATURES

* V

CEO

=120V

* 3 Amp continuous Current

* 6 Amp pulse Current

* Very Low Saturation Voltage

APPLICATIONS

* Automotive Switching Circuit

* Audio Driver Stages

ZTX1055A

C

B

E

E-Line

TO92 Compatible

ABSOLUTE MAXIMUM RATINGS.

PARAMETER

Collector-Base Voltage

Collector-Emitter Voltage

Emitter-Base Voltage

Peak Pulse Current

Continuous Collector Current

Base Current

Power Dissipation at T

amb

=25擄C

Operating and Storage Temperature

Range

SYMBOL

V

CBO

V

CEO

V

EBO

I

CM

I

C

I

B

P

tot

T

j

:T

stg

VALUE

175

120

5

6

3

500

1

-55 to +200

UNIT

V

V

V

A

A

mA

W

擄C
