ZT
-SERIES
ZT90
Triple output 30W ~ 170W
Model name
ZT170
ZT 30-522
Output voltage code
Name of series Output power: 4 types
in 30W ~ 170W
522: 5V, +12V, 鈥?2V
5FF: 5V, +15V, 鈥?5V
525: 5V, +12V, 鈥?V
PC Board Type Power Supply
Features
marking (Low Voltage Directive)
Triple output
12 models, 30W, 60W, 90W, 170W
Wide input voltage range:
100/200VAC user selectable
Isolation between CH1 (5V) and 鹵CH
Compact, low profile and board type
1 year warranty
ZT60
ZT30
(Low Voltage Directive)
1 year warranty
Specifications
1. Input voltage range
2. Output voltage
range
3. Cooling
4. Operating ambient
temperature
(Standard mounting)
85 ~ 132VAC /170 ~ 265VAC (47 ~ 63Hz), 230 ~ 330VDC user selectable
CH1: +5V (5.0 ~ 5.25V), CH2: Fixed, CH3: Fixed
Convection cooling
鈥?0 ~ +60擄C
ZT30, 60, 90 Output derating 鈥?0 ~ +50擄C: 100%, +60擄C: 70%
ZT170: Forced air cooling 鈥?0 ~ +50擄C: 100%, +60擄C: 70% (0.7m/S)
ZT170: Convection cooling
CH1 路路路 鈥?0 ~ +25擄C: 15A, +30擄C: 13A, +40擄C: 12A, +50擄C: 10A, +60擄C: 8A
CH2, CH3 路路路 鈥?0 ~ +50擄C: 100%, +60擄C: 70%
Input-output: 3.75kVAC, Input-chassis: 2.5kVAC one minute each
Approved by UL1950
, CSA950
and EN60950
Conforms to VCCI-class B, FCC class B and VDE class B
Over voltage protection (CH1), Over current protection
Note 1
Note 1
5. Withstand voltage
6. Safety standard
7. EMI
8. Functions
Product lineup
Model name
ZT30-522
ZT30
ZT30-5FF
ZT30-525
ZT60-522
ZT60
ZT60-5FF
ZT60-525
Max.
Nominal
Min.
Max. output
CH output voltage output current output current power
0.3A 3.0A 15.0W
CH1 5V
1.2A
CH2 +12V
0A (2.0A) 14.4W
0A
0.3A 3.6W
CH3 鈥?2V
0.3A 3.0A 15.0W
CH1 5V
1.0A
CH2 +15V
0A (2.0A) 15.0W
0.3A 4.5W
0A
CH3 鈥?5V
0.3A 3.0A 15.0W
CH1 5V
1.2A
CH2 +12V
0A (2.0A) 14.4W
0A
0.3A 1.5W
CH3 鈥?V
0.5A 5.0A 25.0W
CH1 5V
2.5A
CH2 +12V
0A (3.5A) 30.0W
0.5A 6.0W
0A
CH3 鈥?2V
0.5A 5.0A 25.0W
CH1 5V
2.0A
0A (3.5A) 30.0W
CH2 +15V
0A
0.5A 7.5W
CH3 鈥?5V
0.5A 5.0A 25.0W
CH1 5V
2.5A
0A (3.5A) 30.0W
CH2 +12V
0A
0.5A 2.5W
CH3 鈥?V
Total max.
output power UL CSA EN
33.0W
33.0W
33.0W
34.5W
34.5W
34.5W
30.9W
30.9W
30.9W
61.0W
61.0W
61.0W
62.5W
62.5W
62.5W
57.5W
57.5W
57.5W
Model name
ZT90-522
ZT90
ZT90-5FF
ZT90-525
ZT170-522
ZT170 ZT170-5FF
ZT170-525
Nominal
Min.
Max.
CH output voltage output current output current
1A 10.0A
CH1 5V
3.0A
CH2 +12V
0A
(4A)
0.5A
0A
CH3 鈥?2V
1A 10.0A
CH1 5V
2.5A
CH2 +15V
0A
(4A)
0.5A
0A
CH3 鈥?5V
1A 10.0A
CH1 5V
3.0A
CH2 +12V
0A
(4A)
0.5A
0A
CH3 鈥?V
1A 20.0A
CH1 5V
5.0A
CH2 +12V
0A
(6A)
1.0A
0A
CH3 鈥?2V
1A 20.0A
CH1 5V
4.0A
CH2 +15V
0A
(6A)
1.0A
0A
CH3 鈥?5V
1A 20.0A
CH1 5V
5.0A
0A
CH2 +12V
(6A)
1.0A
0A
CH3 鈥?V
Max. output Total max.
power
output power UL CSA EN
50.0W 92.0W
36.0W 92.0W
6.0W 92.0W
50.0W 92.0W
37.5W 95.0W
7.5W 95.0W
50.0W 88.5W
36.0W 88.5W
2.5W 88.5W
100.0W 172.0W
60.0W 172.0W
12.0W 172.0W
100.0W 175.0W
60.0W 175.0W
15.0W 175.0W
100.0W 165.0W
60.0W 165.0W
5.0W 165.0W
: Safety standard approved
Note 1: Duration of peak current shown in ( ): 5 seconds max.
Request customer specification for further details of specifications, outline, characteristics, etc.
Read the instruction manual before usage.
Contact us about delivery before ordering.
