Formosa MS
FEATURES
!
PLASTIC PACKAGE HAS UNDERWRITERS LABORATORY
FLAMMABILITY CLASSIFICATION 94V-0
!
LOW ZENER IMPEDANCE
!
EXCELLENT CLAMPING CAPABILITY
MECHANICAL DATA
!
CASE錛歁OLDED PLASTIC
!
TERMINALS錛歋OLDER PLATED
!
POLARITY錛欼NDICATED BY CATHODE BAND
!
WEIGHT錛?.10 GRAMS
ZS100 THRU ZS330
1WATT SURFACE MOUNT ZENER DIODE
.110(2.8)
.080(2.0)
.040(1.0)
.051(1.3)
.216(5.5)
.185(4.7)
.091(2.3)
.067(1.7)
.051
.008
(1.3)
(.2)
.008
(1.2)
.059(1.5)
.035(.9)
DIMENSIONS IN INCHES AND (MILLIMETERS)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
RATINGS AT 25擄C AMBIENT TEMPERATURE UNLESS OTHERWISE SPECIFIED
STORAGE AND OPERATING TEMPERATURE RANGE -55鈩?TO + 150鈩?/div>
ELECTRICAL CHARACTERISTICS (TA=25鈩僓NLESS OTHERWISE NOTED) VF=1.2V MAX, IF = 200mA FOR ALL TYPES
MAXIMUM REVERSE
MAXIMUM FORWARD
DYNAMIC IMPEDANCES
ZENER
CURRENT
VOLTAGE
錛?/div>
BREAKDOWN
錛?5鈩僒A
錛?/div>
MEASUREMENT
VOLTAGE
25鈩僒A
TYPE
VOLTAGE AND 25鈩僒A
錛營(yíng)F=1.0A
V
Z
I
ZT
Z
ZT
I
ZK
Z
ZK
V
R
I
R
V
F
V
mA
ohms
mA
ohms
V
V
碌A(chǔ)
ZS110
ZS115
ZS120
ZS130
ZS140
ZS150
ZS160
ZS170
ZS180
ZS190
ZS200
ZS210
ZS220
ZS230
ZS240
ZS250
ZS260
ZS270
ZS280
ZS290
ZS300
ZS310
ZS320
ZS330
110
115
120
130
140
150
160
170
180
190
200
210
220
230
240
250
260
270
280
290
300
310
320
330
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
750
750
850
1000
1200
1300
1500
2200
2200
2500
2500
5000
5000
5000
5000
5000
5000
5000
5000
5000
5000
5000
5000
5000
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
5000
5000
5000
5000
5000
5000
5000
5000
5000
5000
8000
9000
9000
9000
9000
9000
9000
9000
9000
9000
9000
9500
9500
9500
80
85
90
95
105
110
120
130
140
150
165
165
170
175
180
190
195
200
210
215
220
225
233
240
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
0.5
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
NOTE鋦癝TANDARD 鹵 20% ,
SUFFIX銆滱銆灺?10%,SUFFIX銆滲銆灺?5%
