ZMZ20M
MAGNETIC FIELD SENSORS
DESCRIPTION
The ZMZ20M is an extremely sensitive magnetic field sensor in a 4 pin
E-line package employing the magneto-resistive effects of thin film
Permalloy. It allows the measurement of magnetic fields or the detection
of metallic parts. The sensor consists of a chip covered with Permalloy
stripes which form a Wheatstone bridge, whose output voltage is
proportional to the magnetic field component Hy. A perpendicular field Hx
is necessary to suppress the hysteresis and this is provided by an internal
permanent magnet.
Hy
Hx
FEATURES
鈥?/div>
Output voltage proportional to magnetic field Hy
鈥?/div>
Magnetic fields vertical to the chip level are not
effective
E-LINE
APPLICATIONS
鈥?/div>
Linear position sensors for process control, door
interlocks, proximity detectors, machine tool
sensing
鈥?/div>
Scalar measurement for compassing
鈥?/div>
Automotive - door switches, engine position and
speed sensing
鈥?/div>
Metering of fluids by sensing rotation of impeller
鈥?/div>
Traffic counting & vehicle-type sensing
鈥?/div>
Measurement of current in a conductor without
connection
ORDERING INFORMATION
DEVICE
ZMZ20M
BOX
Bulk in box (2,000 components per box)
PINOUT
DEVICE MARKING
鈥?/div>
M2M
SIDE VIEW
ISSUE 2 - MARCH 2004
1
SEMICONDUCTORS
