international E 12 standard. Smaller voltage tolerances
are available upon request.
鈾?/div>
These diodes are also available in the DO-41 case with the type
designation ZPU100 鈥?ZPU180.
Cathode Mark
.102 (2.6)
.094 (2.4)
.022 (0.55)
.205 (5.2)
.189 (4.8)
Dimensions are in inches and (millimeters)
MECHANICAL DATA
Case:
MELF Glass Case
Weight:
approx. 0.25 g
MAXIMUM RATINGS
Ratings at 25擄C ambient temperature unless otherwise specified.
SYMBOL
VALUE
UNIT
Zener Current (see Table 鈥淐haracteristics鈥?
Power Dissipation at T
amb
= 25擄C
Junction Temperature
Storage Temperature Range
P
tot
T
j
T
S
1.0
1)
150
鈥?55 to +150
Watts
擄C
擄C
NOTES:
(1) Valid provided that electrodes are kept at ambient temperature.
12/16/98
