Part Number:

ZMDKVG55W-7

www.SunLED.com

3.2mm x 1.6mm BI-COLOR SURFACE MOUNT

LED LAMP

PRELIMINARY SPEC

Features

3.2mmx1.6mm SMT LED,1.8mm THICKNESS.

LOW POWER CONSUMPTION.

WIDE VIEWING ANGLE.

IDEAL FOR BACKLIGHT AND INDICATOR.

PACKAGE : 2000PCS / REEL.

MOISTURE SENSITIVITY LEVEL : LEVEL 3.

RoHS COMPLIANT.

Notes:

1. All dimensions are in millimeters (inches).

2. Tolerance is 鹵 0.1(0.004") unless otherwise noted.

3. Specifications are subject to change without notice.

Operating Characteristics

(T

A

=25擄C)

Absolute Maximum Ratings

(T

A

=25擄C)

Forward Current

Forward Current (Peak)

1/10Duty Cycle

0.1ms Pulse Width

Power Dissipation

Operating Temperature

Storage Temperature

I

F

i

FS

P

T

T

A

Tstg

MDK

VG

(InGaA (InGaA

lP)

lP)

30

185

75

30

150

75

Unit

mA

mA

mW

擄C

Forward Voltage (Typ.)

(I

F

=20mA)

Forward Voltage (Max.)

(I

F

=20mA)

Wavelength Of Peak

Emission (Typ.)

(I

F

=20mA)

Wavelength Of Dominant

Emission (Typ.)

(I

F

=20mA)

Spectral Line Full Width

At Half-Maximum (Typ.)

(I

F

=20mA)

Capacitance (Typ.)

(V

F

=0V, f=1MHz)

V

F

V

F

MDK

(InGaA

lP)

1.95

2.5

VG

(InGaA

lP)

2.1

2.5

Unit

V

V

位

P

650

574

nm

-40 ~ +85

-40 ~ +85

位

D

635

570

nm

螖位

28

20

nm

C

35

15

pF

Part

Number

Emitting

Color

Emitting

Material

Lens-color

Luminous

Intensity

(IF=20mA)

mcd

min.

typ.

497

218

Wavelength

nm

位

P

Viewing

Angle

2

胃

1/2

ZMDKVG55W-7

Red

Green

InGaAlP

InGaAlP

Water Clear

110

70

650

574

40擄

Published Date : FEB 25 ,2008

Drawing No : SDSA6235

V1

Checked : B.L.LIU

P.1/5
