ZL60003
Plastic Optical Fiber Communications -
125 to 250Mbps
Data Sheet
DS5612
Issue 1
June 2002
Ordering Information
ZL60003/TBD TO-46 Package
-20 to +70
0
C
Description
This unique Resonant Cavity Surface-Emitting LED
(RCLED) is designed for optical communications over
Plastic Optical Fiber (POF) in applications such as
IEEE1394b (S100, S200) and 155 Mbps ATM. For very
high speed operation, i.e. above 200 Mbps, an electrical
pre-emphasis circuit is recommended to increase the
bandwidth of the device. ZL60003 is also well suited for
applications where visible light is required, such as in
sensing and positioning.
04.7
01.5
0.6
ANODE
CASE
CATHODE
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Optimized wavelength for Plastic optical fiber
High Bandwith
No threshold
Surface emitting
High coupling efficiency
Hermetically sealed
Applications
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
IEEE1394b
155Mpbs ATM
Homenetworking
Industrial applications
3.7
2.5
14
0.4
Side View
5.4
Bottom View
All dimensions in mm.
The chip is isolated from the case.
Figure 1 - Pin Description
Parameter
Fiber-Coupled Power
Optical Power
Beam Divergence (FWHM)
Bandwidth (3dBel)
Peak Wavelength
Spectral Width (FWHM)
Forward Voltage
Symbol
P
fiber
P
o
2螛
1/2
f
c
位p
鈭單?/div>
V
F
Min
1.2
Typ
Max
Unit
mW
Test Condition
I
F
=30mA (Note1)
I
F
=30mA
I
F
=30mA
I
F
=30mA (Note1)
I
F
=30mA (Note1)
I
F
=30mA (Note1)
I
F
=30mA
2.0
25
125
640
650
660
20
2.3
mW
deg
MHz
nm
nm
V
Note: Fiber: POF 980/1000碌m Step Index, NA=0.48. For high speed communication, a low NA POF or a graded index POF are recommended.
Table 1 - Optical and Electronic characteristics (25
o
C Case temperature)
SEMICMF.017
1
