ZL10036

Digital Satellite Tuner with RF Bypass

Data Sheet

Features

鈥?/div>

QPSK tuner for quadrature down conversion from

L-band to Zero IF

Compatible with DSS and DVB formats (QPSK)

Symbol rate range 1 to 45 MSps

Power & forget,

fully integrated, alignment free,

local oscillator

Integrated baseband filters with bandwidth adjust

from 4 to 40 MHz

Good immunity to strong adjacent undesired

channels

Selectable RF bypass

I虜C bus interface with 3V3 compatible logic levels

Integrated RF loop through for cascaded tuner

applications

Power saving mode/hardware power down

Optimized front end solution when partnered with

Zarlink ZL10312 demodulator

Ordering Information

ZL10036LDG

ZL10036LDF

ZL10036LDG1

ZL10036LDF1

40-pin QFN

40-pin QFN*

*Pb free

-10擄C to +85擄C

(trays)

(tape and reel)

(trays)

(tape and reel)

July 2004

Description

The ZL10036 is a single chip wideband direct

conversion tuner, with integral RF bypass, optimized

for application in digital satellite receiver systems.

The device offers a highly integrated solution to a

satellite tuner function, incorporating an I虜C bus

interface controller, a low phase noise PLL frequency

synthesizer, a quadrature phase split tuner, a fully

integrated local oscillator which requires no production

set up, and adjustable baseband channel filters.

The I虜C bus interface controls all of the tuner

functionality including the PLL frequency synthesizer,

the bypass disable and the baseband gain and

bandwidth adjust.

Applications

鈥?/div>

Satellite receiver systems

Figure 1 - Basic Block Diagram

Zarlink Semiconductor Inc.

Zarlink, ZL and the Zarlink Semiconductor logo are trademarks of Zarlink Semiconductor Inc.
