EMC Components
ZJSR Series
3-Terminal Filters for Signal Line and DC Power Line
Lead(Round)
APPLICATIONS
Home electronic equipment, (TVs, VCRs, CD players, DAT play-
ers, electric musical instruments, PCs, etc.), office automation
equipment (computers, terminals, stand-alone word processors,
fax machines, etc.), factory automation equipment (robots, numeri-
cal control devices, process controllers, etc.), automotive electron-
ics (automotive engine control units, etc.)
BASIC CHARACTERISTICS
Series
Rated voltage Edc
Rated current
Withstand voltage Edc
[Between terminal, No.1, 3 to 2]
Insulation resistance
[DC. 50V for 1 min]
DC resistance[Terminal No.1 to 3]
Operating temperature range
ZJSR
50V
5A
125V
10000M鈩?min.
0.05鈩?max.
鈥?5 to +85擄C
FEATURES
鈥?The ZJSR series combine TDK鈥檚 high performance ferrite bead
and a chip capacitor. This board mounted EMC filter is used to
prevent microcomputer operational errors and stop noise
generation. Most suitable for use in countering radio noise
generated by digital circuits.
鈥?SIP shape with 2.4mm max. thickness, making possible high
density mounting upon a PCB in a row at DIP pitch.
鈥?When using taped product, possible to mount using automatic
equipment.
鈥?Excellent high frequency bypass performance due to short
earth-side capacitor lead.
PRODUCT IDENTIFICATION
ZJSR5101 - 101 TA
(1)
(2) (3)
(1)Series name
(2)Capacitance 101:100pF
(3)Packaging style TA: Taping
(not needed for specification of bulk products)
SHAPES AND DIMENSIONS
TAPING SPECIFICATIONS
A
1
Marking
P
鈭唄
A
鈥?This product should not be used under conditions that exceed those
listed above.
鈥?Please note that this product is an EMC filter, so should not be used as a
surge absorber, etc.
T
鈭唄
酶d
2
(W
2
)
H
酶d
2
酶d
1
(P
1
)
H
1
Dimensions in mm
Series
ZJSR
Component width
8.5max.
A
1
Component height
A
8max.
Component thickness
T
2.4max.
0.5鹵0.05
Lead wire diameter
酶d
1
(round)
0.6鹵0.05
酶d
2
Component pitch
P
12.7鹵1
Feed hole pitch
12.7鹵0.3
P
0
6.35鹵0.4
Feed hole position error
P
1
2.5+0.4, 鈥?.1
Lead pitch
F
1
, F
2
Component alignment
0鹵2
鈭唄
Tape width
W
18+1, 鈥?.5
Cover tape width
12鹵0.3
W
0
9鹵0.5
Feed hole position error
W
1
(4max.)
Cover tape position
(W
2
)
Component bottom position
H
20鹵1
Maximum component height
28max.
H
1
4鹵0.2
Feed hole diameter
0
酶D
0.5max.
Lead wire protrusion
l
1
Lead wire length
l
5鹵1.5
Lead pitch
2.5鹵0.5
f
1
, f
2
鈥?The tolerance of lead pitch is the dimensions when a lead is released
from tape. Not available for bulk packaging.
W
1
l
1
W
P
0
F
1
F
2
BULK SPECIFICATIONS
8max.
CIRCUIT DIAGRAM
Bead cores
1
3
1
2
f
1
f
2
l
3
2
W
0
酶D
0
Chip capacitor
2: Ground terminal
TYPICAL MOUNTING EXAMPLE
2.54mm pitch
ZJSR series
IC LSI
鈥?All specifications are subject to change without notice.
