ZHT431(2) Datasheet

  • ZHT431(2)

  • 221.89KB

  • 7頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

ADJUSTABLE PRECISION
ZENER SHUNT REGULATOR
ISSUE 3 鈥?JANUARY 2003
DEVICE DESCRIPTION
The ZHT431 is a three terminal adjustable
shunt regulator offering excellent
temperature stability and output current
handling capability up to 100mA. The device
offers extended operating temperature
range working from -55 to +125擄C. The
output voltage may be set to any chosen
voltage between 2.5 and 20 volts by
selection of two external divider resistors.
The devices can be used as a replacement
for zener diodes in many applications
requiring an improvement in zener
performance.
ZHT431
FEATURES
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
Surface mount SOT223 and SOT23
packages
TO92 package
2% and 1% tolerance
Maximum temperature coefficient 67
ppm/擄C
Temperature compensated for
operation over the full temperature
range
Programmable output voltage
50碌A(chǔ) to 100mA current sink capability
Low output noise
Wide temperature range -55 to +125擄C
APPLICATIONS
Series and Shunt regulator
Voltage monitor
Over voltage/ under voltage protection
Switch mode power supplies
SCHEMATIC DIAGRAM
V
Z
V
ref
G
nd
4-28
