ZD
-SERIES
Dual output 30W ~ 120W
Model name
ZD 30-2405
[ex.]
24 05
Nominal output voltage
Name of series Output power
CH1: 24V output
CH2: 5V output
PC Board Type Power Supply
78
Features
ZD30
ZD50
ZD75
ZD120
(Low Voltage Directive)
1 year warranty
marking (Low Voltage Directive)
Wide input voltage range
85 ~ 132VAC /170 ~ 265VAC user selectable
12 models, dual output 30 ~ 120W
Isolation between outputs
Applicable to peak current load (ZD75)
1 year warranty
Specifications
1. Input voltage range
2. Output voltage
range
3. Cooling
4. Operating ambient
temperature
(Standard mounting)
5. Withstand voltage
6. Safety standard
7. EMI
8. Functions
85 ~ 132VAC /170 ~ 265VAC (47 ~ 440Hz), 230 ~ 350VDC user selectable
CH1 : +5%, CH2: Fixed (ZD75路路路CH1: 鹵5%, CH2: Fixed)
Convection cooling
鈥?0 ~ +60擄C
Output derating / 鈥?0 ~ +50擄C: 100%, +60擄C: 70%
(ZD75路路路路路路鈥?0擄C: 50%, 0 ~ +40擄C: 100%, +50擄C: 70%, +60擄C: 40%)
Input鈥搊utput: 3.75kVAC, input鈥揊G: 2.5kVAC, output鈥揊G: 500VAC for 1 min.
Approved by UL1950
, CSA950
and EN60950
Conforms to FCC class B, VCCI-class B and VDE class B
Over voltage protection (CH1), Over current protection
Nominal
output voltage
12V
5V
24V
5V
24V
8V
12V
5V
24V
5V
24V
8V
5V
12V
5V
24V
8V
24V
鈥?/div>
24V
12V
5V
24V
5V
24V
8V
Max.
output current
2.1A
1A
1.1A
1A
1.1A
0.7A
4A
1A
2A
1A
2A
0.7A
3.0A
3.0A
3.0A
2.0A
2.0A
2.0A
鈥?/div>
2.0A
9A
2.5A
4.5A
2.5A
4.5A
2A
Max.
output power
25.2W
5W
26.4W
5W
26.4W
5.6W
48W
5W
48W
5W
48W
5.6W
15.0W
36.0W
15.0W
48.0W
16.0W
鈥?/div>
48.0W
108W
12.5W
108W
12.5W
108W
16W
Total max.
output power
30.2W
31.4W
32W
53W
53W
53.6W
51.0W
63.0W
64.0W
48.0W
120.5W
120.5W
124W
: Safety standard approved
Product lineup
Model name
ZD30-1205
ZD30
ZD30-2405
ZD30-2408
ZD50-1205
ZD50
ZD50-2405
ZD50-2408
ZD75-0512
ZD75-0524
ZD75
ZD75-0824
ZD75-0024
ZD120-1205
ZD120
ZD120-2405
ZD120-2408
CH
CH1
CH2
CH1
CH2
CH1
CH2
CH1
CH2
CH1
CH2
CH1
CH2
CH1
CH2
CH1
CH2
CH1
CH2
CH1
CH2
CH1
CH2
CH1
CH2
CH1
CH2
UL
CSA
EN
鈥?/div>
鈥?/div>
鈥?/div>
Request customer specification for further details of specifications, outline, characteristics, etc.
Read the instruction manual before usage.
Contact us about delivery before ordering.
