Ultrabright LED, 酶 5 mm Untinted Non-Diffused

Color

Red

ZD-1790

Type

Technology

AlInGaP on GaAs

Angle of Half Intensity

鹵枚

4擄

Description

The

ZD-1790

series is a clear, non diffused 5 mm LED

for high end applications where supreme luminous

intensity and a very small emission angle is required.

These lamps with clear untinted plastic case utilize the

highly developed ultrabright AlInGaP (AS) and InGaN

technologies.

The very small viewing angle of these devices provide

a very high luminous intensity.

94 8631

Features

D

Untinted non diffused lens

D

Utilizing ultrabright AlInGaP (AS) and

InGaN technology

D

Very high luminous intensity

D

Very small emission angle

D

High operating temperature:

T

j

(chip junction temperature)

up to +125擄C for AlInGaP devices

D

Luminous intensity and color categorized

for each packing unit

D

ESD鈥搘ithstand voltage:

2 kV acc. to MIL STD 883 D, Method 3015.7

for AlInGaP, 1 kV for InGaN

Applications

D

Interior an exterior lighting

D

Outdoor LED panels, displays

D

Instrumentation and front panel indicators

D

Central high mounted stop lights (CHMSL)

for motor vehicles

D

Replaces incandescent lamps

D

Traffic signals and signs

D

Light guide design
