Zero input-output propagation delay
Output-output skew less than 250 ps
Device-device skew less than 700 ps
One input drives nine outputs, grouped as 4/4/1 (Z9309)
10 MHz to 150 MHz operating range, compatible with
CPU and PCI bus frequencies
鈥?Less than 200 ps cycle-cycle jitter, compatible with
Pentium
廬
and Pentium Pro
廬
鈥揵ased systems
鈥?Spread Spectrum Compatible
鈥?Test Mode to bypass PLL (Z9309)
鈥?Available in space-saving 16-pin 150-mil SOIC and
TSSOP package (Z9309), and 8-pin 150-Mil SOIC
package (Z9305)
Block Diagram (Z9305)
REF
PLL
CLKOUT
CLK1
CLK2
CLK3
Block Diagram (Z9309)
PLL
CLK4
REF
CLKOUT
CLKA1
CLKA2
CLKA3
S2
S1
Select Input
Decoding
CLKA4
CLKB1
CLKB2
CLKB3
CLKB4
Cypress Semiconductor Corporation
Document #: 38-07196 Rev. **
鈥?/div>
3901 North First Street
鈥?/div>
San Jose
鈥?/div>
CA 95134 鈥?408-943-2600
Revised December 5, 2001
