Z8E001 Datasheet

  • Z8E001

  • CMOS OTP Microcontroller

  • 212.56KB

  • 49頁

  • ZILOG   ZILOG

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

P
RELIMINARY
P
RODUCT
S
PECIFICATION
1
Z8E001
CMOS OTP M
ICROCONTROLLER
FEATURES
Part
Number
Z8E001
* General-Purpose
s
s
s
1
ROM
(KB)
1
RAM*
(Bytes)
64
Speed
(MHz)
10
One Analog Comparator
16-Bit Programmable Watch-Dog Timer (WDT)
Software Programmable Timers Configurable as:
鈥?Two 8-Bit Standard Timers and One 16-Bit
Standard Timer or
鈥?/div>
One 16-Bit Standard Timer and One 16-Bit Pulse
Width Modulator (PWM) Timer
Microcontroller Core Features
s
All Instructions Execute in one 1
碌
s Instruction
Cycle with 10 MHz Crystal
1K x 8 On-Chip OTP EPROM Memory
64 x 8 General-Purpose Registers (SRAM)
Six Vectored Interrupts with Fixed Priority
Operating Speed: DC - 10 MHz
Six Addressing Modes: R, IR, X, D, RA, & IM
s
s
s
s
s
s
s
s
Additional Features
On-Chip Oscillator that Accepts XTAL, Ceramic
Resonator, LC, or External Clock
Programmable Options:
鈥?EPROM Protect
Power Reduction Modes:
鈥?HALT Mode with Peripheral Units Active
鈥?STOP Mode with all Functionality Shut Down
Peripheral Features
s
s
13 Total Input/Output Pins
One 8-Bit I/O Port (Port A)
鈥?I/O Bit Programmable
鈥?Each Bit Programmable as Push-Pull or Open-
Drain
One 5-Bit I/O Port (Port B)
鈥?I/O Bit Programmable
鈥?Includes Special Functionality:
Stop-Mode Recovery Input
Comparator Inputs
Selectable Edge Interrupts
Timer Output
s
s
Low-Power Consumption
3.0V to 5.5V Operating Range @ 0
擄
C to +70
擄
C
4.5V to 5.5V Operating Range @ -40
擄
C to +105
擄
C
18-Pin DIP,SOIC, and 20-Pin SSOP Packages.
s
s
DS97Z8X1300
PRELIMINARY
1
