Z86217 Datasheet

  • Z86217

  • CMOS Z8 8-BIT MICROCONTROLLERS (POINTING DEVICE/TRACKBALL)

  • 7頁

  • ZILOG   ZILOG

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

P R E L I M I N A R Y
Z86217/C17
CP95KEY1000
P
RELIMINARY
C
USTOMER
P
ROCUREMENT
S
PECIFICATION
Z86217/C17
CMOS Z8
廬
8-B
IT
M
ICROCONTROLLERS
(P
OINTING
D
EVICE
/T
RACKBALL
)
FEATURES
Part
Number
Z86217
Z86C17
* General-Purpose
ROM
(Kbytes)
2
2
RAM*
(Bytes)
124
124
I/O
Lines
14
14
Speed
(MHz)
4
4
s
s
s
s
s
s
s
Permanent Watch-Dog Timer (WDT)
Oscillator Filter
Two Programmable 8-Bit Counter/Timers
Low-EMI Operation
Scalable Trip-Point Buffer
On-Board Pull-Up Resistors
High Drive Ports Can Sink 20 mA Per Pin, with Three
Pins Maximum
s
s
s
18-Pin DIP and SOIC Packages
3.0- to 5.5-Volt Operating Range
0擄C to 70擄C Operating Temperature Range
GENERAL DESCRIPTION
The Z86217/C17 are members of Zilog's Z8
廬
family of
microcontrollers designed to reduce external system com-
ponents and offer easy software/hardware development
tools for pointing device and trackball applications.
The devices feature on-board pull-up resistors, and a
scalable trip-point buffer to accommodate opto-transistor
outputs. The high drive ports are capable of up to 20 mA
(at V
OL
= 0.8-volt) current sinking per pin, with three pins
maximum, providing extra sinking current capability.
The Z86217/C17's permanently enabled Watch-Dog Timer
(WDT) operates upon power-up of the MCU, and provides
added operational reliability for pointing device and
trackball environments.
An oscillator filter assists in separating out high-frequency
noise from the oscillator input pin.
Two on-chip counter/timers with a large number of
selectable modes, offload the system of administering
real-time tasks such as counting/timing and I/O data
communications.
Notes:
Refer to the DC electrical characteristics for detailed specification of the
sinking current.
On the Z86C17, P24-P27 has a 20K pull-up, and P32 has a 47K pull-
down. The Z86217 does not have these functions.
All Signals with a preceding front slash, "/", are active Low, e.g.; B//W
(WORD is active Low); /B/W (BYTE is active Low, only).
Power connections follow conventional descriptions below:
Connection
Power
Ground
Circuit
V
CC
GND
Device
V
DD
V
SS
CP95KEY1000 8/95
1
