XRT6164CP Datasheet

  • XRT6164CP

  • Digital Line Interface Transceiver

  • 456.99KB

  • 10頁

  • EXAR   EXAR

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

XRT6164
Digital Line Interface Transceiver
September 2003
APPLICATIONS
FEATURES
l
l
l
Data Adaption Unit (DAU)
General Purpose TTL Compatible Line Inter-
face
Single 5V Supply
CCITT G.703 Compatible When Used With
Either XR-T6165 or XR-T6166
Low Power
TTL Compatible Digital Inputs and Outputs
Links Remote Equipment at Distances up to
500 Meters Without Equalization
Receive Data Comparator Threshold Storage
Provides Ping-Pong Operation Capability
Loss of Signal Alarm
Dual Matched Driver Outputs
l
l
l
l
l
l
l
GENERAL DESCRIPTION
The XRT6164 is a bipolar analog chip intended for general purpose line interface applications at bit rates up to
1.544Mbps (T1). It contains both receive and transmit circuitry in a 16-pin dual-in-line plastic package. The receiver
is designed for short line applications having a cable loss up to 10dB measured at the half bit rate. The transmitter
has open collector line driver outputs that are capable of handling up to 40mA. When used in conjunction with either
XRT6165 or XRT6166, the chip set provides a 64Kbps codirectional interface as specified in CCITT G.703.
ORDERING INFORMATION
Part No.
XRT6164CP
XRT6164CD
Package
16-Lead 300 Mil PDIP
16-Lead 300 Mil JEDEC SOIC
Operating
Temperature Range
0擄C to +70擄C
0擄C to +70擄C
Rev. 3.0.0
EXAR
Corporation, 48720 Kato Road, Fremont, CA 94538
鈥?/div>
(510) 668-7000
鈥?/div>
FAX (510) 668-7017
