X9C303S8I Datasheet

  • X9C303S8I

  • Digitally Controlled Potentiometer (XDCP)

  • 367.46KB

  • 10頁

  • XICOR   XICOR

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

A
PPLICATION
N
OTE
A V A I L A B L E
AN42 鈥?AN44鈥?8 鈥?AN50 鈥?AN52 鈥?AN53 鈥?AN71 鈥?AN92
Terminal Voltage 鹵5V, 100 Taps, Log Taper
X9C303
Digitally Controlled Potentiometer (XDCP
鈩?/div>
)
FEATURES
鈥?Solid-state potentiometer
鈥?Three-wire serial interface
鈥?100 wiper tap points
鈥擶iper position stored in nonvolatile memory
and recalled on power-up
鈥?99 resistive elements, log taper
鈥擳emperature compensated
鈥擡nd to end resistance, 鹵15%
鈥擳erminal voltages, 鹵5V
鈥?Low power CMOS
鈥擵
CC
= 5V
鈥擜ctive current, 3mA max.
鈥擲tandby current, 750碌A(chǔ) max.
鈥?High reliability
鈥擡ndurance, 100,000 data changes per bit
鈥擱egister data retention, 100 years
鈥?X9C303, 32 k
鈩?/div>
鈥?Packages
鈥?-lead TSSOP
鈥?-lead SOIC
鈥?-pin DIP
DESCRIPTION
The Xicor X9C303 is a digitally controlled potentiome-
ter (XDCP). The device consists of a resistor array,
wiper switches, a control section, and nonvolatile
memory. The wiper position is controlled by a three-
wire interface.
The resistor array is composed of 99 resistive ele-
ments. Between each element and at either end are
tap points accessible to the wiper terminal. The posi-
tion of the wiper element is controlled by the CS, U/D,
and INC inputs. The position of the wiper can be
stored in nonvolatile memory and then be recalled
upon a subsequent power-up operation.
The device can be used as a three-terminal potentio-
meter or as a two-terminal variable resistor in a wide
variety of applications ranging from control, to signal
processing, to parameter adjustment. Digitally-
controlled potentiometers provide three powerful appli-
cation advantages; (1) the variability and reliability of a
solid-state potentiometer, (2) the 鏗俥xibility of com-
puter-based digital controls, and (3) the use of nonvol-
atile memory for potentiometer settings retention.
BLOCK DIAGRAM
U/D
INC
CS
7-Bit
Up/Down
Counter
99
98
97
7-Bit
Nonvolatile
Memory
96
One
of
One-
Hundred
Decoder
2
Store and
Recall
Control
Circuitry
1
0
R
L/
V
L
R
W/
V
W
XDCP
鈩?/div>
is a trademark of Xicor, Inc.
REV 1.1 4/27/01
R
H/
V
H
Transfer
Gates
Resistor
Array
V
CC
V
SS
www.xicor.com
Characteristics subject to change without notice.
1 of 10

X9C303S8I 產品屬性

  • 100

  • 集成電路 (IC)

  • 數據采集 - 數字電位器

  • XDCP™

  • 100

  • 32k

  • 1

  • 標準值 ±400 ppm/°C

  • 非易失

  • 3 線串行（芯片選擇，遞增，增/減）

  • 4.5 V ~ 5.5 V

  • -40°C ~ 85°C

  • 表面貼裝

  • 8-SOIC（0.154"，3.90mm 寬）

  • 8-SOIC

  • 管件
