Series OAC,
(S)MOAC,
X4OAC
AC Output Modules
鈥?Status Indicating LED on
X4 Series and 4A Fuse
鈥?UL, CSA, and CE
鈥?Zero Cross Switching
Solid state I/O switching modules deliv-
er an electrically clean, photo-isolated,
noise-free "output" interface from
logic level control systems to external
loads such as motors, valves, solenoids,
etc. -- or an "input" interface from the
load or sensors to microprocessor or
computer-based logic level systems.
Designed for long, reliable service in
demanding industrial environments.
INPUT SPECIFICATIONS
OAC5
(S)MOAC5
X4OAC5
5
2.5 (4)
6.0 (7.5)
2.0
10
27
240
OAC15
(S)MOAC15
X4OAC15
15
8.5 (10)
18.5 (20)
2.0
10
20
900
OAC24
OAC5A
(S)MOAC24 (S)MOAC5A
X4OAC24
X4OAC5A
24
16.5 (18)
29.0 (30.5)
2.0
10
13.5
2.2K
5
2.5 (4)
6.0 (7.5)
2.0
10
27
240
OAC15A
OAC24A
(S)MOAC15A (S)MOAC24A
X4OAC15A X4OAC24A
15
8.5 (10)
18.5 (20)
2.0
10
20
900
24
16.5 (18)
29.0 (30.5)
2.0
10
13.5
2.2K
Nominal Input Voltage [Vdc]
Min. Input Voltage @ pin 3 [Vdc] (X4 Series)
Max. Input Voltage @ pin 3 [Vdc] (X4 Series)
Must Turn Off Voltage [Vdc]
Typical Input Current [mAdc]
Max. Input Current [mAdc]
Nominal Input Resistance [ohm]
OUTPUT SPECIFICATIONS
Nominal Line Voltage [Vrms]
Max. Line Voltage [Vrms]
Min. Line Voltage [Vrms]
Max. Peak Off-State Voltage [V peak]
Max. Off-State Leakage Current [mArms]
Static Off-State (dv/dt)[V/碌s]
Max. On-State Current [Arms]
Min. On-State Current [mArms]
Max. One Cycle Surge [A peak]
Peak On-State Voltage [V peak]
Max. Turn-On Time [cycles]
Max Turn-Off Time [cycles]
Derating [mA per 藲 above 25藲 C]
Fuse Rating [fast-acting] (X4 Series Only)
120
140
12
400
2.5
200
3
50
100
1.6
1/2
1/2
33
4A
120
140
12
400
2.5
200
3
50
100
1.6
1/2
1/2
33
4A
120
140
12
400
2.5
200
3
50
100
1.6
1/2
1/2
33
4A
240
280
24
600
4.5
200
3
50
100
1.6
1/2
1/2
33
4A
240
280
24
600
4.5
200
3
50
100
1.6
1/2
1/2
33
4A
240
280
24
600
4.5
200
3
50
100
1.6
1/2
1/2
33
4A
漏1998 CRYDOM CORP Specifications subject to change without notice.
FastFax Document No. 304
SERIES OAC.070898, PAGE 1 OF 2
