WC16P332-16GX
68332 MONOLITHIC MICROCONTROLLER
s
68020 Monolithic Microcontroller also available. Please
call factory for more information.
PRELIMINARY*
FEATURES
s
100% CMOS
s
16 MHz Operating Frequency
s
Single 5V Operation
s
System Integration Module (SIM)
鈥?External Bus Support
鈥?Programmable Chip-Select Outputs
鈥?System Protection Logic
鈥?Watchdog Timer, Clock Monitor, and Bus Monitor
鈥?System Protection Logic
鈥?System Clock Based on 32.768kHz Crystal for Low Power
Operation
鈥?Test/Debug Submodule for Factory/User Test and
Development
s
Central Processing Unit (CPU)
鈥?Upward Object Code Compatible
鈥?New Instructions for Controller Applications
鈥?32-Bit Architecture
鈥?Virtual Memory Implementation
鈥?Loop Mode of Instruction Execution
鈥?Table Lookup and Interpolate Instruction
鈥?Improved Exception Handling for Controller Applications
鈥?Trace on Change of Flow
鈥?Hardware Breakpoint Signal, Background Mode
鈥?Fully Static Operation
s
Time Processor Unit (TPU)
鈥?Dedicated Microengine Operating Independently of CPU32
鈥?16 Independent, Programmable Channels and Pins
鈥?Any Channel can Perform any Time Function
鈥?Two Timer Count Registers with Programmable Prescalers
鈥?Selectable Channel Priority Levels
s
Queued Serial Module (QSM)
鈥?Enhanced Serial Communication Interface (SCI),
Universal Asynchronous Receiver Transmitter (UART):
Modulus Baud Rate, Parity
鈥?Queued Serial Peripheral Interface (SPI): 80-Byte RAM,
Up to 16 Automatic Transfers
鈥?Dual Function I/O Ports
鈥?Continuous Cycling, 8-16 Bits per Transfer
s
Static RAM Module with TPU Emulation Capability (TPURAM)
鈥?2-Kbytes of Static RAM
鈥?May be Used as Normal RAM or TPU Microcode
Emulation RAM
1
s
Operating Temperature Range -55擄C to 125擄C
s
Packaging
鈥?132 lead, 24mm (0.950") sq., Hermetic CQFP (Package 505)
(shipped with leads cut and formed).
* This data sheet describes a product under development, not fully
characterized, and is subject to change without notice.
DESCRIPTION
The WC16P332 is a 32-bit microcontroller that includes high
performance data manipulation features and peripheral
subsystems. The WC16P332 is comprised of standard modules
that interface through a common intermodule bus (IMB). The
WC16P332 accommodates expedient development of devices
which are tailored for specific applications.
The Microcontroller includes a 32-bit CPU (CPU32), a system
integration module (SIM), a time processor unit (TPU), a queued
serial module (QSM), and a 2Kx8 SRAM module with TPU
emulation capability.
The Microcontroller can either synthesize an internal clock
signal from an external reference or use an external clock input
directly. Operation with a 32.768khz reference frequency is
standard. System hardware and software allow changes in
clock rate during operation. The Microcontroller module
operation is fully static, therefore register and memory
contents are not affected by clock rate changes.
HCMOS technology makes the typical power consumption of
the Microcontroller low. Power consumption can be greatly
decreased by stopping the system clock. The Microcontroller
instruction set includes a low-power stop (LPSTOP) command
that easily implements this feature.
TYPICAL RATINGS
Num
1
2
3
4
Characteristic
Supply Voltage
V
DD
Supply Current
Clock Synthesizer Operating Voltage
V
DDSYN
Supply Current
VCO on, maximum f
sys
External Clock, maximum f
sys
RAM Standby Voltage
RAM Standby Current
Normal RAM operation
Stanby operation
Power Dissipation
Symbol
V
DD
I
DD
V
DDSYN
I
DDSYN
1.0
4.0
V
SB
I
SB
7.0
40
P
D
455
3.0
mA
mA
V
碌A(chǔ)
碌A(chǔ)
mW
Value
5.0
75
5.0
Unit
V
mA
V
5
6
7
October 1997
White Microelectronics 鈥?Phoenix, AZ 鈥?(602) 437-1520
