W981216AH Datasheet

  • W981216AH

  • 2M x 16 bit x 4 Banks SDRAM

  • 44頁

  • WINBOND

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

W981216AH
2M x 16 bit x 4 Banks SDRAM
Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
3.3V鹵0.3V power supply
Up to 133 MHz clock frequency
2,097,152 words x 4 banks x 16 bits organization
Auto Refresh and Self Refresh
CAS latency: 2 and 3
Burst Length: 1, 2, 4, 8 , and full page
Burst read, Single Writes Mode
Byte data controlled by UDQM and LDQM
Power-Down Mode
Auto-Precharge and controlled precharge
4k refresh cycles / 64ms
Interface: LVTTL
Package: TSOP II 54 pin, 400 mil - 0.80
General Description
W981216AH is a high speed synchronous dynamic random access memory (SDRAM) , organized as 2M words x 4 banks x
16 bits. Using pipelined architecture and 0.20um process technology, W981216AH delivers a data bandwidth of up to 266M
bytes per second (-75). To fully comply to the personal computer industrial standard, W981216AH is sorted into two speed
grades: -75 and -8H. The -75 is compliant to the PC133/CL3 specification, the 鈥?H is compliant to PC100/CL2 specification.
Accesses to the SDRAM are burst oriented. Consecutive memory location in one page can be accessed at a burst length of
1, 2, 4, 8 or full page when a bank and row is selected by an ACTIVE command. Column addresses are automatically generated
by the SDRAM internal counrter in burst operation. Random column read is also possible by providing its address at each clock
cycle. The multiple bank nature enables interleaving among internal banks to hide the precharging time.
By having a programmable Mode Register, the system can change burst legnth, latency cycle, interleave or sequential burst
to maximize its performance. W981216AH is ideal for main memory in high performance applications.
Key Parameters
Symbol
t
CK
t
AC
t
RP
t
RCD
I
CC1
I
CC4
I
CC6
Description
Clock Cycle Time
Access Time from CLK
Precharge to Active Command
Active to Read/Write Command
Operation Current ( Single bank )
Burst Operation Current
Self-Refresh Current
min/max
min
max
min
min
max
max
max
-75 (PC133)
7.5ns
5.4ns
20ns
20ns
85mA
120mA
2mA
-8H (PC100)
8ns
6ns
20ns
20ns
80mA
110mA
2mA
Revision 1.0
-1-
Publication Release Date: March, 1999
