W53322/W53342
60" Voice/Melody/LCD Controller
(ViewTalk
TM
Series)
GENERAL DESCRIPTION
The W53322/W53342 are high-performance 4-bit microcontrollers (碌C) with built-in speech, melody
and 32*48/32*64 LCD driver which includes internal pump circuit. The 4-bit uc core contains dual clock
source, 4-bit ALU, two 8-bit timers, one divider, 20 pin input or output, 7 interrupt sources , 8-level
subroutine nesting for interrupt applications. Speech unit can be implemented with Winbond 60 sec
Power Speech using ADPCM algorithm. Melody unit provides dual tone output and can store up to 1k
notes. Power reduction mode is also built in to minimize power dissipation. It is ideal for games,
educational toys, remote controllers, watches, clocks and other application鈥?products which
incorporate both LCD display and melody.
FEATURES
鈥?/div>
Operating voltage: 2.4 volt ~ 5.5 volt
鈥?/div>
Dual clock operating system
鈭扲C/Crystal
(400 KHz to 4 MHz) for main clock
鈭?/div>
32.768 KHz crystal oscillation circuit for sub-oscillator
鈥?/div>
Memory
鈭?/div>
16k
脳
20 bit program ROM
鈭?/div>
512
脳
4 bit data RAM
鈭?/div>
384 x 4/512
脳
4 bit LCD RAM for W53322/W53342
鈥?/div>
20 input/output pins
鈭扨orts
for input only: 2 ports/8 pins
鈭捍nput/output
ports: 2 ports/8 pins
鈭扨ort
for output only: 1 port /4 pins
鈥ower-down
mode
鈭扝old
function: no operation (except for 32kHzoscillator)
鈭?/div>
Stop mode function: no operation (include 32kHz oscillator)
鈥?/div>
Seven types of interrupts
鈭扚ive
internal interrupts (Divider ,Timer 0, Timer 1, Speech, Melody)
鈭扵wo
external interrupts (Port RC, Port RD)
鈥?/div>
One built-in 14-bit clock frequency divider circuit
鈥?/div>
Two built-in 8-bit programmable countdown timers
鈭扵imer
0: one of two internal clock frequencies (FOSC/4 or FOSC/1024) can be selected
鈭扵imer
1: built-in auto-reload function includes internal timer, external event counter from RC.0 or
TONE output function (can be used as IR carrier output if main clock is 455 kHz)
鈥?/div>
Built-in 18/14-bit watchdog timer for system reset by mask code option
鈥?/div>
Powerful instruction sets
鈥?/div>
8-level subroutine (including interrupt) nesting
Publication Release Date: March 1999
Revision A2
-1-
