W3E16M72SR-XBX
16Mx72 Registered DDR SDRAM
FEATURES
!
Registered for enhanced performance of bus
speeds of 200, 225, and 250 MHz
!
Package:
鈥?219 Plastic Ball Grid Array (PBGA), 32 x 25mm
!
2.5V 鹵0.2V core power supply
!
2.5V I/O (SSTL_2 compatible)
!
Differential clock inputs (CK and CK)
!
Commands entered on each positive CK edge
!
Internal pipelined double-data-rate (DDR)
architecture; two data accesses per clock cycle
!
Programmable Burst length: 2,4 or 8
!
Bidirectional data strobe (DQS) transmitted/
received with data, i.e., source-synchronous data
capture (one per byte)
!
DQS edge-aligned with data for READs; center-
aligned with data for WRITEs
!
DLL to align DQ and DQS transitions with CK
!
Four internal banks for concurrent operation
!
Two data mask (DM) pins for masking write data
!
Programmable I
OL
/I
OH
option
!
Auto precharge option
!
!
!
!
Advanced*
Auto Refresh and Self Refresh Modes
Commercial, Industrial and Military Temperature
Ranges
Organized as 16M x 72
Weight: W3E16M72SR-XBX - 2.5 grams typical
BENEFITS
!
47% SPACE SAVINGS
!
Glueless Connection to PCI Bridge/Memory
Controller
!
Reduced part count
!
Reduced I/O count
鈥?49% I/O Reduction
!
Reduced trace lengths for lower parasitic
capacitance
!
Suitable for hi-reliability applications
!
Laminate interposer for optimum TCE match
!
Upgradeable to 32M x 72 density (contact factory
for information)
* This data sheet describes a product that is not fully qualified or
characterized and is subject to change without notice.
Monolithic Solution
22.3
11.9
66
TSOP
22.3
66
TSOP
12.6
11.9
11.9
11.9
8.3
Actual Size
S
A
V
I
N
G
S
48
TSOP
White Electronic Designs
W3E16M72SR-XBX
25
22.3
66
TSOP
66
TSOP
66
TSOP
12.6
48
TSOP
32
Area
I/O
Count
November 2003 Rev. 1
5 x 265mm2 + 2 x 105mm2 = 1536mm2
5 x 66 pins + 2 x 48 = 426 pins
1
800mm2
219 Balls
47%
49%
White Electronic Designs Corporation 鈥?(602) 437-1520 鈥?www.whiteedc.com
