1W170-01
W170-01
Spread Aware鈩? Frequency Multiplier and Zero Delay Buffer
Features
鈥?Spread Aware鈩⑩€攄esigned to work with SSFTG
reference signals
鈥?Two outputs
鈥?Configuration options allow various multiplication of
the reference frequency, refer to
Table 1
to determine
the specific option which meets your multiplication
needs
鈥?Available in 8-pin SOIC package
Table 1. Configuration Options
FBIN
OUT1
OUT1
OUT1
OUT1
OUT2
OUT2
OUT2
OUT2
FS0
0
1
0
1
0
1
0
1
FS1
0
0
1
1
0
0
1
1
OUT1
2 X REF
4 X REF
REF
8 X REF
4 X REF
8 X REF
2 X REF
16 X REF
OUT2
REF
2 X REF
REF/2
4 X REF
2 X REF
4 X REF
REF
8 X REF
Key Specifications
Operating Voltage: ..........................3.3V 鹵5% or 5.0V 鹵10%
Operating Range: .......................20 MHz < f
OUT1
< 133 MHz
Absolute Jitter: ......................................................... 鹵500 ps
Output to Output Skew: .............................................. 250 ps
Propagation Delay: ................................................... 鹵350 ps
Propagation delay is affected by input rise time.
Block Diagram
FBIN
External feedback connection to
OUT1 or OUT2, not both
Pin Configuration
FBIN
IN
GND
1
2
3
4
8
7
6
5
OUT2
VDD
OUT1
FS1
FS0
FS1
梅Q
FS0
IN
Reference
Input
Phase
Detector
Charge
Pump
Loop
Filter
Output
Buffer
VCO
梅2
Output
Buffer
OUT1
OUT2
