VV6300 Datasheet

  • VV6300

  • Integrated CMOS Colour Image Sensor with on-chip ADC.

  • 50頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

VV5301 & VV6301
廬
Mono and Colour QSIF Digital Video CMOS Image Sensors
The VV5301 and VV6301 are highly integrated digital
output imaging devices based on STMicroelectronics鈥檚
unique CMOS sensor technology. Both of these sensors
require minimal support circuitry and provide an ideal low
cost imaging solution.
VV5301 (monochrome) and VV6301 (colourised) produce
digital video output. The video streams from both devices
contain embedded control data that can be used to enable
frame grabbing applications.
The pixel array of the VV6301 has colour filters forming a
Bayer colour pattern. This sensor requires software to
perform colour processing to allow an image to be
displayed on a PC.
The sensor can perform automatic black calibration to
remove voltage offsets in the video signal path that lead to
offsets in the output image. These offsets are removed
using 2 Digital to Analogue Convertors (DACs). The
automatic black calibration algorithm monitors the average
level of the sensor black pixels and adjusts the input level
to the 2 DACs to remove the offset.
A 2 wire serial interface allows the sensor to be
reconfigured if required.
Key Features
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
鈥?/div>
QSIF resolution sensor
Automatic exposure/gain control
Multiple digital output formats available
I2C interface for sensor control
Integrated 8bit ADC
On board voltage regulator
Automatic Black Calibration
Variable frame rate
Reduced flicker operating modes
Application Areas
鈥?/div>
鈥?/div>
鈥?/div>
Toys
Automotive systems
Intelligent Imaging sensors
Speci鏗乧ations
Maximum pixel
resolution
Effective image
size after colour
processing
Pixel size
164 x 124
160 x 120
Functional block diagram
12.0碌m x 12.0碌m
1.92mm x 1.44mm
Automatic ( to +44dB)
+18dB
36dB
5V DC
+/鈭?/div>
5%
2.9mA (standby)
14.6mA (active)
0
o
C - 40
o
C
(for extended temperature informa-
tion please contact STMicroelec-
tronics)
VERTICAL
SHIFT
REGISTER
PHOTO DIODE ARRAY
DIGITAL
CONTROL
LOGIC
SDA
SCL
Array size
Exposure control
Analogue gain
Signal/Noise ratio
CLKI
CLKO
CLOCK
CIRCUIT
SAMPLE & HOLD
FORMAT
HORIZONTAL SHIFT REGISTER
D[7:0]
SIN
FST
QCK
Supply voltage
Supply current
VV5301-VV6301
Operating
temperature
(ambient)
Package type
ANALOG
VOLTAGE
REFS.
A/D CONVERTOR
48BGA
cd5301-6301f: Rev 3.0, 25 September 2000
Commercial in confidence
1/50
