Reflective Optoswitch
Arrow Retro with Flying Leads
VTR17D1
PRODUCT DESCRIPTION
This series of reflective optical switches combines an infrared emitting diode (IRED) with
an NPN phototransistor (VTR17D1) in a one piece, sealed, IR transmitting plastic case.
The sealed construction improves resistance to moisture and debris. Units have 12",
#26 AWG leads. Refer to VTR16xx for devices with PC. board mounting leads.
ABSOLUTE MAXIMUM RATINGS
Maximum Temperatures
Storage and Operating:
Operating Temperature:
-40擄C to 85擄C
-40擄C to 85擄C
GENERAL CHARACTERISTICS
(@ 25擄C unless otherwise noted)
Parameter
Reverse Voltage
Continuous Forward Current
Forward Voltage Drop
Collector Breakdown Voltage
Emitter Breakdown Voltage
Power Dissipation
Symbol
V
R
I
F
V
F
V
BR(CEO)
V
BR(ECO)
P
D
Text Conditions
I
R
= 100 碌A(chǔ)
Derate 0.73 mA/擄C above 30擄C
I
F
= 20 mA
I
C
= 100 碌A(chǔ)
I
E
= 100 碌A(chǔ)
Derate 0.91 mW/擄C above 30擄C
Input IRED
2.0V Min.
40 mA Max.
1.8V Max.
30V Min.
5.0V Min.
50 mW Max.
Output Detector
PACKAGE DIMENSIONS inch (mm)
VTR17D SCHEMATIC
PerkinElmer Optoelectronics, 10900 Page Ave., St. Louis, MO 63132 USA
Phone: 314-423-4900 Fax: 314-423-3956 Web: www.perkinelmer.com/opto
24
1
2
