Agilent VTO-0995-SMA,
VTO-1070-SMA
Voltage Controlled Oscillator
Data Sheet
Features
鈥?Operating frequency:
9.95328 GHz or 10.754 GHz
鈥?Output power (50鈩?load):
2 dBm minimum
Description
The VTO-0995-SMA/
VTO-1070-SMA provides a
fundamental, low jitter source as
a key component for the data
re-timing in the transmitter
subsystem and clock and data
recovery in the receiver of the
10 Gb fiber optic systems.
The oscillator uses an extremely
high performance low noise
Agilent Silicon Bipolar transistor
in conjunction with a
hyperabrupt varactor diode to
provide the tuning capability.
The oscillator output is then
coupled through a filter to the
output.
Functional Block Diagram
鈥?Modulation sensitivity:
5 to 10 MHz/V
鈥?Tuning voltage:
0 to 10 Volts
Amp
Output
鈥?Low jitter (Less than 50 femto
seconds from 50 KHz to 80 MHz)
鈥?Frequency drift over 0擄C to +75擄C:
20 MHz
鈥?1.180" x 0.950" x 0.400"
Applications
鈥?Transmitter and receiver sub-
systems for OC-192/STM-64
applications
鈥?10 GHz source
VTO-0995-SMA, VTO-1070-SMA Absolute Maximum Ratings
[1]
Parameter
Positive Supply Voltage
Tuning Voltage
Operating Temperature
Storage Temperature
Units
V
V
擄C
擄C
Ratings
0 to +10
0 to +12
-10 to +95
-40 to +130
Note:
1. Operation of this device in excess of any of these limits may cause permanent damage.
