VSC8169QR Datasheet

  • VSC8169QR

  • Telecommunication IC

  • 18頁

  • ETC

掃碼查看芯片數據手冊

上傳產品規格書

PDF預覽

VITESSE
SEMICONDUCTOR CORPORATION
Preliminary Data Sheet
VSC8169
Features
鈥?16:1 Multiplexer Up to 2.7Gb/s
鈥?Targeted for SONET OC-48 / SDH STM-16 (FEC)
Applications
鈥?Differential LVPECL Low-Speed Interface
OC-48 (FEC) 16:1 SONET/SDH
MUX with Clock Generator
鈥?On-Chip PLL-Based Clock Generator
鈥?128-Pin 14x20mm PQFP Package
鈥?Single +3.3V Supply
General Description
The VSC8169 is a 16:1 multiplexer with integrated clock generator for use in SONET/SDH systems oper-
ating at a standard 2.48832Gb/s data rate or a forward error correction (FEC) data rate up to 2.7Gb/s. The inter-
nal clock generator uses a Phase-Locked Loop (PLL) to multiply either a 77.76MHz (up to 84.38MHz-FEC) or
a 155.52MHz (up to 168.75MHz -FEC) reference clock in order to provide the 2.48832GHz (up to 2.7GHz -
FEC) clock for internal logic and output retiming. For use with the VSC9210 FEC Encoder/Decoder chipset
running at 2.654208Gb/s, a reference clock of 82.944MHz (serial rate divided by 32) should be used. The 16-bit
parallel interface incorporates an on-board FIFO eliminating loop timing design issues by providing a flexible
parallel timing architecture. The device operates using a 3.3V power supply, and is packaged in a thermally-
enhanced plastic package. The thermal performance of the 128-pin PQFP allows the use of the VSC8169 with-
out a heat sink under most thermal conditions.
VSC8169 Block Diagram
CLK16I+
CLK16I-
D0+
D0-
Write
Pointer
Input Register
16x5 FIFO
Output
Retime
DO+
DO-
D15+
D15-
REFCLKO+
REFCLKO-
Reset
CLK16O+
CLK16O-
REFCLK+
REFCLK-
F_FREQSEL
Read
Pointer
FIFO
Control
CLKO+
CLKO-
FIFO_WAR
Divide by 16
Divide
by 2
2.6GHz
PLL
G52230-0, Rev 3.6
01/02/01
漏
VITESSE
SEMICONDUCTOR CORPORATION
鈥?741 Calle Plano 鈥?Camarillo, CA 93012
Tel: (800) VITESSE 鈥?FAX: (805) 987-5896 鈥?Email: prodinfo@vitesse.com
Internet: www.vitesse.com
Page 1
